Preparation of Demo

2.3 Unzip Downloaded Files

(1) Preparation for display demo using STM32 F4-Discovery
1. Make the project folder "demo_stm32f4_psp" and place the file "stm32f4discovery_fw.zip" into
this folder.
2. Unzip the file "stm32f4discovery_fw.zip". The folder "STM32F4-Discovery_FW _Vx.x.x" will
be created.
3. Unzip the file "demo_stm32f4_psp1.zip" described in the Table 2-1, ATM0430D5 Download File.
The folder "S1D13781", "STM32F4_s1d13781_Demo" and
"STM32F4_s1d13781_Demo_embFlash" will be created.
4. Move folder "S1D13781" to the following folder.
"\demo_ stm32f4_psp\STM32F4-Discovery_FW_Vx.x.x\Libraries\"
5. Move folder "STM32F4_s1d13781_Demo" and "STM32F4_s1d13781_Demo_embFlash" to the
following folder.
"\demo_STM32 F4_psp\STM32F4-Discovery_FW _Vx.x.x\Project\"
*Vx.x.x shows version number.
Project folder： demo_stm32f4_psp
└ STM32F4-Discovery_FW_V1.1.0
├ Project
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
├ Libraries
...
Contents provided by Epson are the folders in Bold Italic letters
10
├ STM32F4_s1d13781_Demo
EWARM
... ├
│├ STM32F4-Discovery_S1D13781.eww
...
│
├ readme.txt
inc
├
src
└
STM32F4_s1d13781_Demo_embFlash
├
EWARM
... ├
STM32F4-Discovery_S1D13781.eww
│├
...
│
readme.txt
├
inc
├
src
└
├ CMSIS
S1D13781
├
│ ├ readme.txt
inc
│ ├
│ │├ S1D13781.h
src
│ ├
│ └ image_header_file_generator
│
└ STM32F10x_StdPeripf_Driver
├ Releae_Notes.html
├ inc
└ src
Figure 2-1 Structure of the Project Folder (STM32)
Seiko Epson Corporation
Demo using external SPI flash
Project file
Readme for Project
Directory for header files
Directory for source files
Demo using internal flash
Project file
Readme for Project
Directory for header files
Directory for source files
S1D13781library
Readme file for S1D13781library
Directory for header files
Directory for source files
Directory for image header file generator
STM32F4 library
ReleaseNote for STM32 F4
Directory for header files
Directory for source files
