Epson S5U13781R00C100 Demonstration Manual page 11

(2) Preparation for writing data into flash memory
1. Unzip the file "flash_psp1.zip" described in the Table 2-1, ATM0430D5 Download File. The
project folder "flash_psp" is created.
2. Unzip the MPSSE-SPI library "libMPSSE-SPI.zip" downloaded in Section 2.1, Instruction for
Tool Download and Install. The folder "libMPSSE-SPI" will be created.
3. Double click the "b.bat" icon in the folder "\libMPSSE-SPI\Release-SPI\samples".
A command window is opened. Type "3" to select "SPI-Static".
Copy following three files from the folder "\libMPSSE-SPI\Release-SPI\samples\SPI" into the
project folder: "flash_psp".
ftd2xx.h
libMPSSE.a
libMPSSE_spi.h
This completes embedding the MPSSE-SPI library into the M25P16 write project folder:
"flash_psp".
Project folder: flash_psp
ReadMe.txt
├
├ EPSON_LCDC_REF.sln
***.cpp
├
├ ***.h
├ libMPSSE.a
├ libMPSSE.h
├ ftd2xx.h
pix
├
... ├ image*_480x272.ppm
...
image*_320x240.ppm
├
...
Contents provided by Epson are written in Italic letter.
S5U13781R00C100 Demonstration Manual
(Rev. 2.1)
Figure 2-2 Structure of the Project Folder (Flash)
Seiko Epson Corporation
Preparation of Demo
Contents
Solution file
Source file
Header file
MPSSE library from FTDI
MPSSE header file from FTDI
D2XX header file from FTDI
Directory for demo image data
Demo image data for PSP panel (in PPM format)
Demo image data for QVGA panel (in PPM format)
11
