Parameter
CH1 Channel: ON\OFF
CH2 Channel: ON\OFF
CH1 Amplification: X1, X2,
X4, X8
CH2 Amplification: X1, X2,
X4, X8
Work mode: UTH\TAR
Work level: from 10% to
100%
Work margin: from 2% to
10%
Period dimension: 0,1s 0,2s
0,5s 1s
CH1 Buzzer: ON\OFF
Clean the skin near the area to be treated; connect the amplifier to I-TECH
PHYSIO EMG; connect the 2 concentric electrodes to the cables with
dedicated connector and the reference pregelled electrode squared to the
2mm male plug. Pay attention when placing the concentric electrodes near
the muscular belly, while the square electrode (mass reference) should be
positioned in an area where there is proximity to a bone tissue (for example
on the wrist or ankle).
Reference Test Mode
Once the parameters of the previous screen have been set, pressing the
directional arrow on the right accesses the "reference test" menu, this
function allows the recording of the reference contraction for each channel
IACER Srl
Description
It's possible to activate or deactivate this
channel.
It's possible to activate or deactivate this
channel.
It's possible to amplify the input signal
(bioelectronic signal of the patient) X1, X2, X4,
X8
It's possible to amplify the input signal
(bioelectronic signal of the patient) X1, X2, X4,
X8
It's possible to select the work mode,
between UTH (Under Threshold) and TAR
(Target, Keep Level)
It's possible to set the maximum percentage
when the desired contraction level is reached
It's possible to set the tolerance when the
desired contraction level is reached (only for
the TAR (Target, Keep Level) mode)
It's possible set the period on which
amplitude calculations of the signal taken are
performed (ds 0,1s 0,2s 0,5s a 1s)
It's possible activate or deactivate the
acoustic signal of work
