Rehab Programs - I-Tech PHYSIO 4 User Manual

W26 • Interferential (medical program)
Cable type: TYPE 1 (see Figure 1 - Cable type.)
The interferential
interference of two sinusoidal currents at different
frequencies applied to the patient; the resultant
current, endogenously generated, is a new kind of
current. Its
difference and the sum of the two initial frequencies
and their multiples. There are several advantages to
this current: easy transfer through the skin, no
sensation of pain for the patient, an excellent
therapeutic effect in depth, no electrolytic effects.
Session duration: 15 minutes, one phase.
Electrodes' positioning: as shown in the diagram beside.
Intensity: adjusted in order to produce a good tingling, not painful.
W27 • Ione generator CC (medical program)
Cable type: TYPE 2 (see Figure 1 - Cable type.) active channels: CH1 CH3
The program generates a continuous current which is the classic waveform
used for the ionophoretic treatments, being capable to maximize the ion
transport. See what is described in programs W09 and W10 regarding the
principles of action. It is possible to find a slight reddening of the skin at
the end of the program; the redness normally disappears within an hour of
the end of the program.
Session duration: 20 minutes.
Electrodes' positioning: transversally to the area to be treated: place the
electrode with the drug over the painful area and the other transversely.
Intensity: such as to produce a strong tingling on the treated area.

REHAB programs

Medical
Prg Prog.
Yes/No
R01 Yes
R02 Yes
IACER Srl
therapy is
frequencies are
Description
Total time
Denervated
20min
Total time
Partially
25min
denervated
Wave with 3s
based on the
respectively the
PHASE 1 PHASE 2
33
PHASE 3
MNPG178
