Contact the manufacturer for other information.
W09-W10 • Iontophoresis 1/Iontophoresis 2 (medical programs)
Cable type: TYPE 1 (see Figure 1 - Cable type.)
At the end of the program, the skin could turn slightly red; any reddening
usually vanishes a few minutes after the end of the program. Select
channel 1 or channel 2 (select both channels only if you need to stimulate
two different areas).
Channels 3 and 4 are disconnected.
W09 and W10 programs differ only in terms of the level of frequency. W09
program works with a frequency of 1000Hz, while the second with a
frequency of 1500Hz. On the other hand, this aspect can cause greater
irritability of the skin. In the case of the W10 program, it is advisable to
check for reddening of the skin 5 minutes into treatment (stop the
program and remove the electrodes to check the skin): in the case of
excessive reddening, use program W09 instead.
Session duration: 20 minutes.
Electrodes' positioning: transversally to the area to be treated: place the
electrode with the drug over the painful area and the other transversely.
Intensity: such as to produce a strong tingling in the treated area.
W11 • Haematomas (medical program)
Cable type: TYPE 1 (see Figure 1 - Cable type.)
Consult a doctor before using this program to treat haematomas. Few
applications carried out within a few hours of the bruise are
recommended. A combination of various types of square-wave impulses
has a graduated draining effect on the area to be treated, in fact impulses
at different frequencies drain the area at different depths.
Session duration: 20 minutes.
Electrodes' positioning: form a square above the area to be treated as
shown in Figure 2.
Intensity: to be adjusted between the threshold of perception and pain.
