A bar indicating the start and end of a contraction will appear on the
display while the electronic stimulator is working. The periods of
muscular contraction (bold bar) and the periods of recovery (dotted
or striped bar) are graphically visualized under the bar with a cursor.
This enables the user to know exactly when a contraction starts.
9. At the end of the first phase, I-TECH PHYSIO 4/EMG At the end of the
first phase, the I-TECH PHYSIO 4/EMG cancels the previously
selected intensity, and warns the user with an intermittent signal; to
continue with the program, increase the intensity again. Three
sound signals will advise of the end of the program. At the end of the
program, switch off the I-TECH PHYSIO 4/EMG and remove the
cables. Attach the electrodes to the transparent films and put them
in their original packaging
Option to simultaneously increase the intensity on all 4 channels
Select the desired program as instructed above.
Increase the intensity of all the channels up to at least 1 by pressing the
relative keys, and then press the Up arrow keys to increase the intensity
for all 4 channels. To decrease the intensity, press the Down arrow keys.
Skip phase control
Press the right arrow button during normal program operation to skip to
the next phase.
Pause / stop program control
During normal program operation, press the OK button once to
momentarily pause the normal work cycle. Press the OK button again to
restart the program.
