Commissioning • Touch screen calibration

5 Touch screen calibration

B&R touch screen devices are equipped with a B&R touch controller that supports hardware calibration. As a
result, devices are pre-calibrated when delivered. This is an advantageous feature when replacing devices of the
same model or type since it avoids having to recalibrate the new device. Nevertheless, calibrating the device is still
recommended in order to achieve the best results and to better adapt the touch screen to the user's preferences.

5.1 Single-touch (analog resistive)

5.1.1 Windows 10 IoT Enterprise 2015 LTSB

After starting Windows 10 IoT Enterprise 2015 LTSB on the Panel PC for the first time, the corresponding touch
screen driver is installed automatically.
On all other devices, the touch screen driver must be installed in order to operate the touch screen. The necessary
driver is available in the Downloads section of the B&R website (www.br-automation.com).

5.1.2 Windows Embedded 8.1 Industry Pro

After starting Windows Embedded 8.1 Industry Pro on the Panel PC for the first time, the corresponding touch
screen driver is installed automatically.
On all other devices, the touch screen driver must be installed in order to operate the touch screen. The necessary
driver is available in the Downloads section of the B&R website (www.br-automation.com).

5.1.3 Windows 7 Professional / Ultimate

After installing Windows 7 on the device, the touch screen driver must be installed in order to operate the touch
screen. The necessary driver is available in the Downloads section of the B&R website (www.br-automation.com).

5.1.4 Windows Embedded Standard 7 Embedded / Premium

A touch screen driver will be installed automatically if a touch controller is detected during the Windows Embedded
Standard 7 installation.
The touch screen driver must be installed manually if a touch controller was not detected when installing Windows
Embedded Standard 7 or if an Automation Panel has been connected after installation. The necessary driver is
available in the Downloads section of the B&R website (www.br-automation.com).

5.2 Multi-touch (projected capacitive - PCT)

5.2.1 Windows 10 IoT Enterprise 2015 LTSB
Microsoft multi-touch drivers are installed when Windows 10 IoT Enterprise 2015 LTSB is installed on the device.
Once the installation of Windows 10 IoT Enterprise 2015 LTSB has completed, the device can be operated imme-
diately.

5.2.2 Windows Embedded 8.1 Industry Pro

Microsoft multi-touch drivers are installed when Windows Embedded 8.1 Industry Pro is installed on the device.
Once the installation of Windows Embedded 8.1 Industry Pro has completed, the device can be operated imme-
diately.

5.2.3 Windows 7 Professional / Ultimate

Microsoft multi-touch drivers are installed when Windows 7 is installed on the device. Once the installation of
Windows 7 has completed, the device can be operated immediately.

5.2.4 Windows Embedded Standard 7 Premium

Microsoft multi-touch drivers are installed when Windows Embedded Standard 7 Premium is installed on the device.
Once the installation of Windows Embedded Standard 7 Premium has completed, the device can be operated
immediately.
