Wiring Instructions - If Flowmeter Fitted With Din Connector - Macnaught M Series Instruction Manual

Notes
Analogue outputs are available as an auxiliary display signal by including the following LCD displays with
your flow meter. These may be fitted to the meter or remote (wall mount) types.
DRA Small display with analogue output module
ERA Large display with analogue output module
Note: Consult the following instruction sheets if the flow meter is fitted with an LCD Display.
Display Part Number:
Instruction Sheet:
Pulser Wiring Instructions - Models M,F, CR and S - If fitted with DIN connector
Note: The below wiring instructions are only valid for flowmeters fitted with DIN connector
Analogue Output (4-20mA)
DR DRA
DR013 DR014
1 hall & 1 reed
Hall Effect
Dual Reed
Reed
Dual Hall
Hall Effect 1
Sensor Cable (1.5 meters)
Remote or Meter Mount
Remote Mount only
ER ERB
MS574 MS392
Reed
Reed
Hall Effect 2 Temperature
Part number: MXD-C1.5S
ERA ERS
MS476 MS531
