- Page 1 MS244BR 0902 0002 The experts in fluid technology Positive Displacement Flowmeters M50 Modular series instruction manual M50 Pulse • M50 Standard LCD • M50 Deluxe LCD • From serial No. CXXXX...
- Page 2 Always advice. The modular M50 series meters are retain this manual for future reference. This Flow Meter has incorporated the only available in either Aluminium, If you have any problems with the oval rotor principal into its design.
- Page 3 Installation 1] it is recommended that when setting up pipework for meter installations a Flow Inlet bypass line be included in the design. Bypass Line This provides the facility for a meter to be removed for maintenace without interrupting production. (See Fig.1) 2] Use thread sealant on all pipe Strainer...
- Page 4 Service Instructions Rotor #1 Disassembly 4] Remove the o’ring (Item 2) from the o’ring groove in the meter cap (Item 4). Ensure that the fluid supply to the meter is disconnected, and the line 5] Remove rotors (Item 3). Note the pressure released before...
- Page 5 Meter Parts Listing Key: Indicates recommended Spare Parts to stock Item Rec. Part or Set Part Description Parts Off. MS524S Meter Body Module (Aluminium) MS524BRS Meter Body Module (Bronze) MS518S 2” BSP Flange (Aluminium) MS518NS 2” NPT Flange (Aluminium) MS518BRS 2”...
- Page 6 Display Parts Listing 22 23 MS280S MS576MS Deluxe Standard LC Display LC Display Rec. Item Part or Set Part Description Parts Off. (Order from this column only) MS280S Deluxe LCD Display (Complete) MS279S Mounting Adaptor Plate MS117S Adaptor Screws MS69S LC Display Unit MS118S LC Display Mounting Screws...
- Page 7 Meter Specifications Pulse Pulse with Standard Pulse with Deluxe Meter Type LC Display LC Display Flow Ranges Litres/minute - US Gall/min 15 to 350/ 4 to 92 15 to 350/ 4 to 92 Above 5 Centipoise 15 to 350/ 4 to 92 33 to 300/9 to 79 33 to 300/9 to 79 Below 5 Centipoise...
- Page 8 Note: This warranty does not form part of twelve (12) months from the date of Macnaught shall, as its option repair or of, nor does it constitute, a contract sale of the Products to the enduser (the...
