Wetted Parts - Macnaught M Series Instruction Manual

Wetted Parts

Model 006
Component
Meter Body
Meter Cap
Rotor Shafts
Rotors - Standard
- High Temp.
Rotor Bushes
O-Ring
Model 009
Component
Meter Body
Meter Cap
Rotor Shafts
Rotors - Standard
- High Temp.
- High Viscosity.
Rotor Bushes
O-Ring
K - FEP/PTFE Encapsulated
SS - Stainless Steel 316 /304
Al - Aluminium AA610
CA - Carbon
FKM - Viton ®
PPS - Polyphenylene Sulphide
PVDF - Polyvinylidene Flouride
FFKM - Perfluoro Elastomer
Hast C - Hastelloy C ™
Type 'F' Type 'S'
Al Al
Al Al
SS SS
SS SS
- -
CA CA
FKM FFKM
Type 'F' Type 'S'
Al Al
Al Al
SS SS
SS SS
- -
SS SS
CA CA
FKM FFKM
Type 'M' Type 'CR'
SS PPS
SS PPS
SS Hast C
SS PPS
SS -
CA -
FFKM FFKM
Type 'M' Type 'CR'
SS PPS
SS PPS
SS Hast C
SS PPS
SS -
SS -
CA -
FFKM FFKM
Page 16 of 20
