- 2 - INSTALLATION

2.1 MOUNTING

This fixture may be mounted on the tripod stand, in any location, provided there is adequate room for
ventilation. There are two methods of mounting this fixture:
• Using the tripod stand.
• Using a clamp on the two clamp hanging bolts.
When carrying out any installation, always comply scrupulously with all the regulations (particularly re-
garding safety) currently in force in the country in which the fixture's being used. Adjust the angle of the
each of the four lights on the fixture by loosening both knobs and tilting the fixture. After finding the
desired position, retighten both knobs.
• When selecting installation location, take into consideration access and routine maintenance.
• Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature
changes or restricted ventilation.
ADJUSTMENT
KNOB
4MOON - 4MOONCL
TRIPOD
MOUNTING
POINT
Fig.2
MOUNTING
CLAMPS
CLAMP
CONNECTION
