3.3 MENU STRUCTURE

MAIN LEVEL PROGRAMMING LEVELS DESCRIPTION
DMX Mode 512 d001-512 Sets DMX starting address
Sound Active Mode SND Sets Sound Active mode and sensitivity
AUTO
Auto Programs
Sets Auto Program and speed
S--
Auto Program Speed

3.4 AUTOMATIC MODE

If no DMX control signal is present at the DMX INPUT, the unit independently runs through its show pro-
gramme:
• Press the button MENU repeatedly until [AUTO].
• Press the button ENTER to confirm.
• Press the button MENU until the display reads [S- -].
• Use the button UP/DOWN to select the operating speed of the program.
• Press the button ENTER.

3.5 SOUND MODE

This fixture has a built-in sound-triggered program. To trigger this program, please see the below
instructions:
• Press the button MENU until [SND] is displayed.
• Press the button ENTER to confirm.
• Then, use the Sound adjustment knob (1) to adjust the sensitivity of the program to the sound received
from the microphone

3.6 MASTER/SLAVE MODE

This mode will allow you to link up the units together without a controller. Choose a unit to function as the
Master. The unit must be the first unit in line; other units will work as slave.
MASTER SETTINGS
• Connect the fixtures with DMX cables
• Set the master fixture to one of the 2 standalone operating modes: automatic or sound mode.
SLAVE SETTINGS
• Set the DMX starting address of the Slave(s) to [001].

3.7 LIGHT ADDRESSING

The 4MOON/4MOONCL has 4 lights which must all be addressed. While these lights come preaddressed
from the factory, the section below demonstrates how to address them. This is important, so that they will
operate properly.
Please see the instructions and drawings below for further details on how to set the DIP switches on each
light.
