- Underpan sensors providing anti-crushing protec-
tion - Fig. 5/e
- Mechanical safety gear - Fig.6/a.

3.3) Main electrical safety features

Protection against overcurrent, overload, acciden-
tal contacts, and direct and indirect contacts.
- Differential circuit breaker on power supply system.

3.4) Warning signs

The lift is fitted with various warning signs:
- Emergency switch must be pressed before operation
by hand - Fig. 2/e.
- Lift dataplate.
- Manual arm and platform release sign.

3.5) Supply package

- Track and mounting connections - Fig.7/a.
- Frame with carriages - Fig. 6 and Fig.7/b.
- Set of arms- Fig. 7/f.
- Platform - Fig. 7/c.
- Casing - Fig. 7/d.
- Handwheel for manual operation - Fig. 7e.
The lift system must be installed by skilled
staff authorised by VIMEC.
FIG.7
