vimec V59 Use And Maintenance

Hide thumbs Also See for V59:

Advertisement

Quick Links

Download this manual
USE AND MAINTENANCE
ASSEMBLY INSTRUCTIONS
SPARE PARTS CATALOGUE
DATE ____________ APPROVED ____________
VIMEC reserves the right to make any modification and change to its products at any time in compliance with the technical
STAIRLIFT MODEL V59
MANUAL CODE
7512022/B
01/09/2016
developments.
Original instructions
Vimec s.r.l
Via Parri, 7 - 42045 Luzzara - Reggio Emilia- Italy
Tel. + 39 0522 970 666 - Fax. + 39 0522 970919
www.vimec.biz
Page 03 - 13
Page 14 - 21
Page 22 - 46

Advertisement

loading
Need help?

Need help?

Do you have a question about the V59 and is the answer not in the manual?

Questions and answers

Related Manuals for vimec V59

Summary of Contents for vimec V59

  • Page 1 Page 14 - 21 SPARE PARTS CATALOGUE Page 22 - 46 MANUAL CODE 7512022/B DATE ____________ APPROVED ____________ 01/09/2016 VIMEC reserves the right to make any modification and change to its products at any time in compliance with the technical developments.

  • Page 2: Ec Declaration Of Conformity

    _________________________________________________________ “EC” DECLARATION OF CONFORMITY The manufacturer: Via Parri n.7 , 42045 Luzzara (R.E.) ITALIA Tel. 0522/970666 r.a. Fax 0522/970919 (Name and address of the person authorised to compile the technical file: Name: Marco Marchetti Address Via Parri n.7, 42045 Luzzara (R.E.) ITALY - Tel. +39/0522/970666) states on his own responsibility that the stair lift for seated passengers type: V 59 –...

  • Page 3: Use And Maintenance

    USE AND MAINTENANCE GENERAL CONTENTS 1. Unit and manufacturer identification Page 04 2. After-Sales Service Page 04 3. Description of unit Page 05 4. Technical data Page 07 5. Intended and improper uses Page 08 6. Preparing the lift for operation Page 08 7.
  • Page 4 1) UNIT AND MANUFACTURER IDENTIFICATION I - 42045 Luzzara (RE) I - 42045 Luzzara (RE) Via Parri,7 - Tel. +39 0522 970 666 Via Parri,7 - Tel. +39 0522 970 666 TYPE TYPE SERIAL Nr. (N°) - - - - SERIAL Nr.
  • Page 5 3) DESCRIPTION OF UNIT FIG.1 3.1) Description Load equipment - Fig.1 It is composed of: - bearing structure - buffer panels - plastic protections (Fig. 1/a) - footrest (Fig. 1/b) - seat with armrests (Fig. 1/c) - armchair with seat (Fig. 1/e) - seat with backrest (Fig.
  • Page 6 3.5) Components - Rail and fastenings (Fig. 4) - Carriage (Fig. 7/a) - Unit and footrest (Fig. 1) - Support with seat (Fig. 1) Only VIMEC skilled staff can carry out the installation of the unit. FIG.7...

  • Page 7: Technical Data

    3.6) Technical directives 3.6) Technical directives 2014/30/EEC 2014/35/EEC 006/42/EEC 4) TECHNICAL DATA - Traction gear Irreversible worm screw reduction gear VIMEC, 1/60 ratio - Performances Running direction Forward/Backward Speed (upwards/downwards) 0.1 m/s Capacity 1 person Safe working load 130 kg / 286 Lbs Gradient curved sections from 0°...
  • Page 8 5) INTENDED AND IMPROPER USES 5.1) Intended uses Stairlift Mod. V59 is been designed for the transport of SEATED person, with STRAIGHT OR CURVED rail and VARIABLE gradient, to be installed on staircases with the following features: - Environment: Indoor (Temperature 10-60°, humidity max. 70%)
  • Page 9 WARNING: Operation by not authorized persons 6.2) Electrical connection Power supply cable is 3x1.5 mm2 is not permitted. The key to enable the operation of (poles number per section). the machine shall be always kept in a safe place and The electrical device of the stairlift shall be connected to it may be accessible only to authorized persons.
  • Page 10 FIG.11 7.3) Unit provided with remote control panel for the attendant (option) If the user is not self-sufficient, the operation must be entrusted to an attendant, by means of a portable control panel with a keyswitch (Fig. 12/d), Up/Down controls (Fig. 12/e/f). During operation with portable control panel, all unit sa- feties remain active (sensitive edges, final limit switch, over-run device, emergency stop).

  • Page 11: Safety Systems

    It operates during downward motion in case of traction tion monthly. If the unit operations are not stopped, elements breakage or if the unit exceeds a preset speed DO NOT USE the unit!! Call in an authorised VIMEC during descent. technician at once.
  • Page 12 9.2) Defects - Possible causes - Solutions Competence: O - Trained operator Defects Possible causes Possible solutions Too long stopping distance Brake Replace (by VIMEC Authorised operator) The unit does not move Key switch Turn the key on “ON” in both directions Power failure...

  • Page 13: Wiring Diagrams

    Defects Possible causes Possible solutions The unit does not move in both Any safety device operated Apply to VIMEC skilled staff directions The unit does not move in both Control panel not correctly Insert the correct coding directions only when the portable...

  • Page 14: Table Of Contents

    ASSEMBLY INSTRUCTIONS GENERAL CONTENTS 1. System supply condition Page 15 2. Installing the lower rail Page 16 3. Installing the upper rail Page 18 4. Carriage assembly Page 19 5. Positioning the charging station Page 19 6. Connecting the power supply unit Page 20 7.

  • Page 15: System Supply Condition

    1) SYSTEM SUPPLY CONDITION - Rail sections comprising two pipes one of which kept in position by connections - Loose connection components with dowels - Intermediate fittings complete with components - Stairlift complete with support - Power supply unit - Floor controls (option) FIG.1 FIG.2 Head connection...

  • Page 16: Installing The Lower Rail

    2) INSTALLING THE LOWER RAIL FIG.5 - Use the assembly markings (Fig. 3/b) to identify the first section of rail, with the bend (Fig. 3/a) starting from the top floor. NOTE: If there are no bends, find the first straight sec- tion (Fig.
  • Page 17 WARNING: The rail fixing screws (Fig. 7/a) must be FIG.8 tightened to a torque of 30 Nm. - Use the assembly markings (Fig. 3/b) to identify the section of rail with feet (Fig. 8/a) to be placed just above the bend just installed (Fig. 8/b). - Position the rail correctly for installation (Fig.

  • Page 18: Installing The Upper Rail

    3) INSTALLING THE UPPER RAIL - Place the spacers (Fig. 11/a) (order them from the Vimec service department since they are not included in the supply package) at each end of the first section of rail installed (Fig. 11/b) (bend) and lock them firmly in position by turning the lever as shown (Fig.

  • Page 19: Carriage Assembly

    4) CARRIAGE ASSEMBLY FIG.15 The carriage must be fitted into the rail by using the equipment (Fig. 14/a) supplied. Insertion can be made both on the top or bottom of the rail. Should the bottom be preferred, it is necessary to disassemble the first rail section, insert the equipment and then install the unit.

  • Page 20: Connecting The Power Supply Unit

    6) CONNECTING THE POWER SUPPLY UNIT FIG.21 - If the charge station is installed, connect the cables leading from the station direction to the power supply unit cables. - Connect the 230 V 50 Hz power supply to the power socket (Fig.

  • Page 21: Installation Checks

    9) INSTALLATION CHECKS FIG. 24 - Make sure that the position of the rail complies with the measurements indicated in the installation drawing provided. - Make sure that the unit is horizontally positioned. If this is not the case, check that the rails are parallel, check that the distance between the rails, when measu- red vertically, is 240 mm.

  • Page 22: Spare Parts Catalogue

    SPARE PARTS CATALOGUE CONTENTS OF THE CATALOGUE 1. Frame Page 23 2. Seat Page 25 3. Footrest Page 27 4. Carriage Page 29 5. Electrical system Page 37 6. Guards Page 39 7. Motorization Page 41 8. Rail Page 43 9.

  • Page 23: Frame

    FRAME...

  • Page 25: Seat

    REVOLVING SEAT...

  • Page 37: Electrical System

    ELECTRICAL SYSTEM...

  • Page 39: Guards

    GUARDS...

  • Page 41: Motorization

    MOTORIZATION...
