Main Mechanical Safety Features - vimec V65 B.I. Original Instructions Manual

- on/off key or button - Fig.2/i.
- motor - Fig. 3/a.
- transmission components - Fig. 3/b (units with gra-
dient < 20°).
- electric system - Fig. 3/c.
As an option, the machine can be also supplied
complete with double drive chain (Fig. 3 bis) and
micro-chain (Fig.3 bis).
Track - Fig. 4
Comprises:
- Rail - Fig. 4/a.
- Wall mounts - Fig. 4/b.
- Charging station or busbar - Fig. 4/c.
- Step feet (optional) - Fig. 4/d.

3.2) Main mechanical safety features

- Protection arms - Fig. 5/a.
- Safety flaps - Fig. 5/b.
- Sensitive edges providing anti-collision and anti-
shearing protection on lift body - Fig. 5/c.
- Sensitive edges providing anti-collision and anti-
shearing protection on platform - Fig. 5/d.
