be fully open in work mode.
FIG.55
To remove any possible clearances, a load of around
75-100 kg must be applied to the platform (it is sufficient
that an installer gets onto the footboard to remove such
clearance).
Now, reset the clinometer by making a jumper on the
rear of the card (Fig. 53/a); the sound of the card indi-
cates that the setting is in progress.
Press the "bell" push-button.
a
Remove the jumper.
The buzzer will indicate when the reset is completed.

12) PREPARING THE STAIRLIFT FOR SETUP

Glue the magnet (Fig. 55/a) supplied to the bottom end
of the top rail as shown in Fig. 55.
36
