C
ONTENTS
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Fastener Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Note: Please read and understand these instructions before assembling the parts.
Note: Remove all items from the shipping cartons and arrange them in a convenient location.
Refer to the illustrations on the following pages.
If you need additional information, contact Wenger Corporation using the information below.
©Wenger Corporation 2015
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1(507) 455-4100 • www.wengercorp.com
UltraStor
Cover Panel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
End Cover Panel Installation . . . . . . . . . . . . . . . . . . . . .4
Center Cover Panel Installation . . . . . . . . . . . . . . . . . . .7
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Printed in USA 12/15
Installation Instructions
Cover Panel
™
Part #250C880-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger UltraStor Cover Panel
Summary of Contents for Wenger UltraStor Cover Panel
- Page 1 Note: Remove all items from the shipping cartons and arrange them in a convenient location. Refer to the illustrations on the following pages. If you need additional information, contact Wenger Corporation using the information below. ©Wenger Corporation 2015 Printed in USA 12/15 Part #250C880-02 Wenger Corporation, 555 Park Drive, P.O.
- Page 2 Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual.
- Page 3 EQUIRED OOLS The following tools must be supplied by the installer to install the Wenger Cover Panel: Drill 3/16” Drill Bit • 3/8” Drill Bit • #2 Philips Screwdriver (7” overall length max) • 5/32” Hex Driver (7” overall length max) •...
- Page 4 OVER ANEL NSTALLATION OVER ANEL NSTALLATION 1. With the package laid flat, carefully remove the Cover Panel from the package and insert the two Plastic Glide Tacks into the bottom of the Cover Panel, centered and 2-3” from each end. 2.
- Page 5 OVER ANEL NSTALLATION ONTINUED 5. Using the 3/16” drill bit, drill 12 holes (9 holes for 68” tall cabinets) into the side panel of the cabinet to be covered. NOTE: Do not drill into a shelf or cross member. Measure before drilling so that the hole is 1-2” from the nearest horizontal surface to allow clearance for tools.
- Page 6 OVER ANEL NSTALLATION ONTINUED 6. Raise the Cover Panel into position covering the cabinet side panel and flush with the front edge as in Step 3. 7. Clamp securely in position using at least two non-marring padded clamps. 8. Insert all 12 of the supplied #8 1-3/8” Wood Screws (9 are used on 68” cabinets). Do not over-torque or strip out the screws.
- Page 7 OVER ANEL NSTALLATION ONTINUED ENTER OVER ANEL NSTALLATION Use the following steps ONLY when a smaller cabinet is adjacent to a larger cabinet with a cover panel in place on the larger cabinet. 1. Install the Cover Panel using the procedures in “End Cover Panel Installation” on page 4. 2.
- Page 8 EPLACEMENT ARTS Note: The following parts are contained in the Cover Panel Carton. Contact Wenger for replacement part information. Item Qty Description Cover Panel Screw, Machine, 1/4-20 x 2.359” 12 Screw, Wood, #8 x 1-3/8” Plastic Guide Tack Screw, #8 x 1-1/4”...
