RightAngle 48 HALF MOON ON R-STYLE Manual

K&A MANUFACTURING
6703 ZINSER ST., SCHOFIELD, WI 54476
PHONE: 800.298.4351 FAX: 866.882.9475
www.raproducts.com
VERSION DATED: 9/27/11
LEVELING GLIDE
STEP 1
ITEM # PART #
1 VARIES R-STYLE WORKSTATION 24" DEEP
2 VARIES 24" DEEP WORKSURFACE
3 10143 48x24 HALF MOON WORKSURFACE
4 800512 2 X 2 WORKSURFACE JOINER PLATE
5 29SL 29SL POST LEG
6 51708 M5 x 18mm SQ/PH/WSHR HEAD WOOD SCREW 24
INSTRUCTION # 52702
TOOLS REQUIRED FOR ASSEMBLY:
CORDLESS DRILL
#2 PHILLIPS HEAD DRIVER BIT OR
#2 SQUARE HEAD DRIVER BIT
LEVEL
READ ALL THE INSTRUCTIONS
BEFORE BEGINNING
1
6
A
4
DESCRIPTION
R-STYLE (2) 24" DEEP AND (1) 48" HALF MOON WORKSTATION ASSEMBLY
INSTRUCTIONS:
STEP 1: AFTER ASSEMBLING THE 24" DEEP WORKSTATIONS 1 , CENTER (2)
JOINER PLATES 4 ON ONE OF THE WORKSTATIONS IN THE LOCATIONS SHOWN
BELOW LEFT IN STEP 1 . ATTACH THE JOINER PLATES TO THE WORKSURFACE
USING (4) WOOD SCREWS 6
ARE PROVIDED. SEE DETAIL A. DO NOT OVER-TIGHTEN THE SCREWS. USE A
LOW TORQUE SETTING ON THE DRILL.
STEP 2: CENTER (2) JOINER PLATES
WORKSURFACES 2 THAT WILL BUTT THE STRAIGHT EDGE OF THE HALF MOON
WORKSURFACE 3 AS SHOWN BELOW IN DETAIL B. ATTACH THE JOINER PLATES
TO THE WORKSURFACES USING (4) WOOD SCREWS
PLATE. NO PILOT HOLES ARE PROVIDED.
6
4
DETAIL A
B
DETAIL B
QTY.
2
2
1
4
2
, (2) IN EACH JOINER PLATE. NO PILOT HOLES
4 ON THE END EDGES OF OF THE 24"
6 , (2) IN EACH JOINER
STEP 2
2
PAGE 1 OF 2
