Parts List - Linear Technology DC1755A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 4 CIN3, CIN5, CIN7, CIN9
3 12 COUT1 to COUT3, COUT4 to COUT6,
COUT11 to COUT13, COUT14 to COUT16
4 8 COUT7 to COUT10, COUT17 to COUT20
5 2 C1 to A, C1 to B
6 8 C1, C8, C9, C10, C13, C20, C21, C22
7 8 C2, C11, C14, C23, C31, C32, C33, C34
8 2 C4, C16
9 2 C2 to A, C2 to B
10 2 C3 to A, C3 to B
11 3 C7, C19, C28
12 4 L1, L2, L3, L4
13 1 RB to A
14 1 RB to B
15 19 R1, R11, R12, R16, R20, R25, R36, R45, R46,
R50, R54, R55, R59, R62, R69, R112, R113,
R116, R118
16 2 R1 to A, R1 to B
17 6 R2, R17, R37, R51, R57, R107
18 2 R2 to A, R2 to B
19 2 R3 to A, R3 to B
20 9 R3, R4, R24, R26, R31, R38, R39, R61, R63
21 2 R8, R43
22 4 R15, R33, R49, R70
23 2 R18, R52
24 4 R19, R21, R53, R56
25 2 R30, R67
26 2 U1, U2
27 4 U3, U4, U5, U6
Bias Supply and UVLO Circuit
1 1 C29
2 1 C25
3 1 C26
4 1 C27
5 1 C30
6 1 D1
7 1 D2
8 1 L5
9 1 R105
10 1 R106
DEMO MANUAL DC1755A
PART DESCRIPTION
CAP , 180μF 20% 16V OSCON
CAP , 1210 22μF 20% 16V X5R
CAP , 7343 330μF 20% 2.5V POSCAP
CAP , 1206 100μF 20% 6.3V X5R
CAP , 0603 470pF 10% 25V NPO
CAP , 0603 0.22μF 10% 25V X7R
CAP , 0603 2.2μF 10% 16V X7R
CAP , 0603 100pF 5% 25V NPO
CAP , 0603 68pF 5% 25V NPO
CAP , 0603 2200pF 25V X7R
CAP , 0603 1μF 20% 25V X5R
IND, 0.47μH 20%
RES, 0603 13.3k 1% 1/10W
RES, 0603 20k 1% 1/10W
RES, 0603 0Ω JUMPER
RES, 0603 20k 1% 1/10W
RES, 0603 1Ω 5% 1/10W
RES, 0603 6.8k 1% 1/10W
RES, 0603 523Ω 1% 1/10W
RES, 0603 10k 1% 1/10W
RES, 0603 100k 5% 1/10W
RES, 0603 2.87k 1% 1/10W
RES, 0603 59.0k 1% 1/10W
RES, 0603 10Ω 1% 1/10W
RES, 0603 40.2k 1% 1/10W
IC, DUAL OUTPUT BUCK CONVERTER
INTEGRATED MOSFET, DC/DC CONVERTER
CAP , 0603 2.2μF 10% 16V X7R
CAP , 0603 1μF 20% 25V X5R
CAP , 0805 10μF 10% 25V NPO
CAP , 0603 0.1μF 10% 16V X7R
CAP , 0603 10pF 5% 50V NPO
DIODE, BAV170 SOT23
DIODE SHOTTKY SOD326
INDUCTOR 27μH 20%
RES, 0603 20k 1% 1/10W
RES, 0603 10k 1% 1/10W
MANUFACTURER/PART NUMBER
SANYO 16SVP180MX
TDK C3225X5R1C226M
SANYO 2R5TPE330M9L
MURATA GRM31CR60J107ME39L
AVX 06033A471KAT2A
TDK C1608X7R1E224K
MURATA GRM188R61C225KE15
AVX 06033A101JAT2A
AVX 06033A680JAT2A
MURATA GRM188R71E222MA01
AVX 06033D105MAT2A
WÜRTH 744355147
VISHAY CRCW060313K3FKEA
NIC NRC06F2002TRF
VISHAY CRCW06030000Z0EA
NIC NRC06F2002TRF
VISHAY CRCW06031R00JNEA
VISHAY CRCW06036K80FKEA
VISHAY CRCW0603523RFKEA
VISHAY CRCW060310K0FKEA
YAGEO RC0603JR-07100KL
VISHAY CRCW06032K87FKEA
VISHAY CRCW060359K0FKEA
NIC NRC06F10R0TRF
VISHAY CRCW060340K2FKEA
LINEAR TECHNOLOGY LTC3860EUH
FAIRCHILD FDMF6707B
MURATA GRM188R61C225KE15
AVX 06033D105MAT2A
AVX 08053D106MAT2A
AVX 0603YC104KAT2A
MURATA GQM1885C1H100JB01
DIODES INC., BAV170
NXP PMEG2005AEA
WÜRTH 7447789127
NIC NRC06F2002TRF
VISHAY CRCW060310K0FKEA
dc1755af
7
