DEMO MANUAL DC1755A
PARTS LIST
ITEM QTY REFERENCE
11 1 R90
12 1 R93
13 1 R97
14 1 R100
15 1 U7
16 1 U8
Additional Circuit Components
1 0 CIN2
2 0 CIN4, CIN6, CIN8, CIN10 to CIN12
3 0 COUT21 to COUT26, COUT31 to COUT36
4 0 COUT27 to COUT30, COUT37 to COUT48
5 0 R5, R6, R7, R9, R10, R13, R14, R23, R27,
R28, R29, R32, R34, R35, R40, R41, R42, R44,
R47, R48, R58, R60, R64, R65, R66, R68, R71,
R72, R87, R88, R89, R91, R92, R94, R95, R96,
R103, R104, R108, R110, R111, R114, R115,
R117, R119
6 0 C3, C5, C6, C12, C15, C17, C18, C24
7 0 Q2, Q3
8 0 R73, R74, R77, R78, R83, R84, R85, R86
9 0 R80, R82, R101, R102
10 2 Q1, Q4
11 2 R75, R76
12 2 R79, R81
Hardware/Components (For Demo Board Only)
1 4
2 12
3 6
4 6
5 24 E1 to E11, E14, E16, E17 to E27
6 3 JP1 to JP3
7 3 XJP1 to XJP3
8 6 J1 to J4, J11, J12
9 2 J7, J8
10 1 J9
11 1 J10
8

PART DESCRIPTION

RES, 1206 0Ω JUMPER
RES, 0603 100Ω 5% 1/10W
RES, 0603 105k 1% 1/10W
RES, 0603 127k 1% 1/10W
IC, STEP DOWN REGULATOR, DFN
IC, VOLTAGE MONITOR, DC-3
CAP , SANYO SVP-F8
CAP , 1210
CAP , 7343H
CAP , 1206
RES, 0603
CAP , 0603
MOSFET, TO-252
RES, 0603
RES, 2010
MOSFET, TO-252
RES, 0603 10k 1% 1/10W
RES, 2010 0.010Ω 2% 1W
STANDOFF , SNAP ON
NUT, BRASS #10-32
RING, LUG #10
WASHER, TIN, PLATED BRASS
TURRET
HEADER, 3 PIN
SHUNT, 2mm CTRS
STUD, TEST PIN
CON, BNC, 5 PINS
HEADER, DOUBLE ROW, RIGHT ANGLE
SOCKET, DOUBLE ROW
MANUFACTURER/PART NUMBER
VISHAY CRCW12060000Z0EA
VISHAY CRCW0603100RFKEA
VISHAY CRCW0603105KFKEA
VISHAY CRCW0603127KFKEA
LINEAR TECHNOLOGY LT3502EDC
LINEAR TECHNOLOGY LT6703IDC-3
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
VISHAY SUD50N03-09P
VISHAY CRCW060310K0FKEA
IRC LRC-LRF2010LF-01-R010-F
KEYSTONE 8831
ANY
KEYSTONE 8205
ANY
MILL MAX 2501-2-00-80-00-00-07-0
SAMTEC TMM-103-02-L-S
SAMTEC 2SN-BK-G
PEM KFH-032-10
CONNEX 112404
MILL-MAX 802-40-008-20-001000
MILL-MAX 803-43-008-20-001000
