- Page 1 Sauna Heater Installation and Manual...
-
Page 2: Technical Information
Any changes to the sauna heater without authorization is forbidden. TO BE NOTED rust! TECHNICAL INFORMATION Table 1. Sauna minimum and 8...21 m³ a maximum volume 143 mm 702mm Optional exhaust outlet at 110 mm the back(horizontal) Required temperature... - Page 3 Watercontainer volume type 30 l Glassdoor Adjustable legs Guiding plates of combustion air (for cleaner burning) Included Optional " & Height of Connecting Flue SAWO middle part by about 246mm and 90° angled smoke pipe as for by 177mm higher.
-
Page 4: Before Installation
Table 2: CE marking SAWO Model SAWO 21 Fuel Wood Fire safety (initiation to adjacent elements) safety distances see table “SAFETY DISTANCES” Emit of dangerous substances Temperature of smoke fuel in connecting 464°C fuel, °C, (when stove doors closed) 16kW... -
Page 5: Installation Area
Size of the Sauna room SAWO wood burning sauna heater should be installed in a sauna room that follows If the sauna is made of bare massive log and used during winters, the volume must be multiplied by 1.5 which is bigger than the actual volume. For every... -
Page 6: Safety Distances
180 degrees and placing the kingpin to the other side of the cover hatch. SAFETY DISTANCES Table 3. Safety distances to combustible materials Sawo 21 On either side: 250 mm Behind the heater: 250 mm In the front:... -
Page 7: Sauna Stones
Sauna Stones It is recommended to only use peridotite, olivine-dolerites and olivine stones which Place the larger stones on the bottom, with the largest surface of the stone facing the sauna heater’s steel surface. Place the stones on the side cases as well and fairly by 10- 15 cm on top of the middle duct. -
Page 8: Sauna Water
INSTRUCTION FOR USE AND HEATING THE SAUNA HEATER Fuel Only natural wood must be used as a fuel for the heater. Dimensions of the wood that Wood is the only material that should be burned in the heater. Never use materials with Heating heating ash drawer can be open 25 mm, up to restrictor. -
Page 9: Safety Instructions
SAFETY INSTRUCTIONS heater may burn your skin. Don’t leave any combustible material inside the safety distance dimensions. Never cover the heater or outer cover air blowholes. IN CASE OF SOOT FIRE (ALSO IF IT HAS ALREADY BEEN EXTINGUISHED) ALWAYS INFORM THE EMERGENCY CENTRE! WARRANTY cover possible transport, unloading or installation costs or other similar costs. - Page 10 Subject to change without notice. ¡ ¢ £ ¤ ¡ ¥ ¤ ¦ § ¨ © ¤ ¢ £ ¤ ¡ ¥ ¤ ¦...
