TLP Pro 525T, 725T, and 1025T Series • Setup Guide (Continued)
Connecting the Power injector
These touchpanels are powered by a power injector, which must be purchased
separately. Figure 4 shows the Extron XTP PI 100. Your power injector may
look different.
Connect a straight-through Ethernet cable from the power injector to a switch
or router (see figure 4,
switch or router to the power supply input. A second straight-through cable
2
( ) carries the network information and 48 VDC from the power injector to the
touchpanel LAN/PoE connector (see figure 3,
power cord to a convenient 100 VAC to 240 VAC, 50-60 Hz power source (
Alternatively, use an Ethernet cable to connect the XTP/LAN/PoE+ port of the
interface to a PoE+ switch
Reset Modes: a Brief Summary
The TLP Pro 525T, 725T, and 1025T Series touchpanels offer the following reset modes (see the TLP Pro 525, 725, and 1025
Series User Guide for complete information):
Use Factory Firmware — Use this mode with Toolbelt software to replace firmware in the event of conflicts arising from
•
uploading a firmware update.
With the unit powered off, press and hold the Reset button (see figure 3,
Reset All IP Settings — Use this mode to reset all network settings without affecting user-loaded files.
•
Press and hold the Reset button for 6 seconds. After the Reset LED (
Reset button.
Reset to Factory Defaults — Use this mode to return the touchpanel to factory default settings.
•
Press and hold the Reset button for 9 seconds. After the Reset LED flashes three times, release and momentarily press the
Reset button.
NOTES:
• The factory configured passwords for all accounts on this device have been set to the device serial number.
Passwords can be changed during configuration. Passwords are case sensitive.
• If the device is reset to default settings, the password is the default password configuration. The default password
is (for either
extron
Enable or Disable DHCP Client — Use this mode to toggle between DHCP enabled and DHCP disabled. Press the Reset
•
button five times, consecutively. After the fifth press, do not press the button again within 3 seconds. If DHCP was enabled, it
is now disabled and the Reset LED blinks three times. If DHCP was disabled, it is now enabled and the Reset LED blinks six
times.
Setup Menu
Figure 5 shows the Setup menu Status screen for the
TLP Pro 725T model. The menu screens for all other models are very
similar.
Press the Menu button ( B
the five available screens (Status, Network, Display, Audio, and
Advanced) by pressing the appropriate button in the navigation bar
at the top of the screen (for more information, see the TLP Pro 525,
725, and 1025 Series User Guide).
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Extron Safety and Regulatory Compliance Guide
For information about replacing and disposing of batteries, see the TLP Pro 525, 725, and 1025 Series User Guide at
www.extron.com.
Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
4
1 ). This cable carries network information from the
F
, on page 3). Connect the IEC
or accounts).
admin user
) to open the Setup menu. Select any of
on the Extron website.
© 2020 Extron — All rights reserved.
All trademarks mentioned are the property of their respective owners.
~
100-240V 50-60Hz
0.4A MAX
3 3 3
1 1 1
To network switch
Figure 4. Connecting to a Power Injector
3 ).
C ) while reapplying power to the unit.
E
) flashes twice, release and momentarily press the
Status Display
Network
Info Network
IP Address:
Model: TLP Pro 725T DHCP: Off
Host Name:
Part Number: 60-1562-02
Firmware
Version: 1.02.0000.b003
Audio
Bootloader
Version: 1.03.0000
Master Volume:
Master Mute:
PoE: Active
Setup Menu: Status Screen for TLP Pro 725T
Figure 5.
www.extron.com
XTP XTP PWR
PWR
2 2 2
To touchpanel
Audio Advanced Exit
Display
192.168.254.251 Resolution: 1024x600
Project: 1024x600
TLI-AB-CD-EF Sleep Timer: 5 Minutes
Advanced
100 Controller IP: 192.168.254.250
Off Project Size: 1/197 MB
68-2831-54 Rev. B
09 20
