CODELOCKS CODELOCK 2000 ELECTRONIC Series Installation Instructions Manual page 2

Box Contents
Check the contents of the box are correct
according to the model
1 Front Plate
2 Lever Handles (x2)
3 Knob Handles (x2)
4 Back Plate
5 Gaskets (x2)
6 Sprung Spindle
6a Split Spindle (x2)
7
1.5v AA Batteries (x4)
8 Philips Head through Fixing Bolts (3)
(1 spare)
9
Allen Keys
10 2x Cable connections for REM 1 and REM 2
11 Mortice Latch, Strike & 4 screws
12 Latch Support post
13 2 Bolt Mortice lock & Strike
14 Double Europrofile Cylinder & 3 Keys
15 Europrofile Cylinder Escutcheons
15a Keyhole Escutcheons
This box should also contain an Installation Template and Programming Instructions.
Tools Required
• Power Drill • Hammer / mallet
• Drill bits 25, 16, 12 & 10mm • Chisel 25mm
• Philips screwdriver • Stanley knife
2
2K_4K Installation.indd 2-3
4010 2010 4020 2020
• • • •
• - • -
- • - •
• • • •
• • • •
• • - -
- - • •
• • • •
• • • •
• • • •
• • • •
• • - -
• • - -
- - • •
- - • •
• • • •
• • - -
• Adhesive tape, pencil,
bradawl, Tape measure
• Pliers and hacksaw for
cutting bolts
Box Contents
1
2
3
7
6a
9
11
10 12
4 5
8
13
14
15 15a
6
3
