- Page 1 Installation Instructions 2K_4K Installation.indd 1 1/3/05 4:26:03 pm...
- Page 2 Box Contents Box Contents Check the contents of the box are correct according to the model 4010 2010 4020 2020 Front Plate • • • • Lever Handles (x2) • • Knob Handles (x2) • • Back Plate • • •...
-
Page 3: Operations Check
OPERATIONS CHECK SPECIAL FIXING NOTE INSTALLATION 4010 & 2010 LOCKS REMOTE RELEASE OPTION STEP 2 All door locks should be installed with a degree of The lock has 2 sets of terminals for remote release, precision to ensure that all components are vertically Keeping the drill level and square, drill a 25mm hole Remove the battery cover and install the 4 x AA labelled REM 1 and REM 2 on the printed circuit... - Page 4 STEP 5 STEP 8 STEP 13 Diagram D Fitting the strike plate Fix the latch with the wood screws, with the bevel Cut one of the fixing bolts to the required length; i.e. towards the doorframe. door thickness plus approximately 20mm. If correct Position the strike plate on the doorframe so that it cut another to the same length.
- Page 5 INSTALLATION 4020 & 2020 LOCKS STEP 1 STEP 4 Model 4020/2020 is a complete locking unit with all the parts necessary for a new installation, or the total replacement of an existing lock. Lightly mark a height line on the edge and both faces Fold the template accurately along the dotted line of the door, and the door jamb, to indicate the top of and tape it to the door face with the top in line with...
- Page 6 DIMENSIONS STEP 10 STEP 14 CL4010 & CL4020 models are illustrated below. 63mm CL4020 These sizes also apply to the CL2010 & CL2020 models. Position the back plate over the inside spindle, and Check that the deadbolt will project and retract by 49mm connect the mating cables.
- Page 7 C O D E L O C K S L L C C O D E L O C K S LT D C O D E L O C K S C H I N A LT D C A L I F O R N I A , U S A N E W B U R Y R G 1 9 8 AT J I N S H A , G U A N G D O N G U N I T E D K I N G D O M...
