CL400 - Code Change Instructions
Many Codes to Choose From
The CL400 code chamber (CL410 and CL420) consists of 13 buttons from which the code is selected, and a 'C'
button which is used to re-set the chamber after an incorrect entry, and which must always be used as the first
digit of a code. Buttons may only be used ONCE in a code. For example, 1212 is not possible.
A CL400 code, or combination, can be entered in any order or sequence; e.g. 1234 can be 4321 or 1342 or
whatever sequence is most convenient to remember. With 13 buttons, a total of 8,191 different codes are
available, any of which can be entered in any sequence.
The total is arrived at as follows:
Most people will set a code in the range of 4 to 7 digits, and the total number of codes in this range is 5,434. The
lock is factory set with a randomly selected 5 digit code starting with the 'C' button. The code is not recorded by
the factory. The code can be changed as often as required to any other 5 digit code. Every new code must start
with the 'C' button. Using the spare tumblers, the code length can be changed to 4 or 6 digits. Shorter codes are
possible, but 1 or 2 digit codes are not recommended.
https://codelocks.zohodesk.eu/portal/en/kb/articles/cl400-code-change-instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CL410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CODELOCKS CL410

Summary of Contents for CODELOCKS CL410

  • Page 1 Many Codes to Choose From The CL400 code chamber (CL410 and CL420) consists of 13 buttons from which the code is selected, and a ‘C’ button which is used to re-set the chamber after an incorrect entry, and which must always be used as the first digit of a code.
  • Page 2 ON TOP: See diagram below. DO NOT force the tumblers in. 6. Replace the code chamber plate carefully with the 2 red screws. 7. Check the operation of the new code, and make a written note of it before reinstalling the lock. https://codelocks.zohodesk.eu/portal/en/kb/articles/cl400-code-change-instructions...
  • Page 3 GUARANTEE If any Codelocks mechanical lock should develop a fault, at any time due to manufacturing, just call the Codelocks helpline and arrange for it to be repaired free of charge.
  • Page 4   https://codelocks.zohodesk.eu/portal/en/kb/articles/cl400-code-change-instructions...
  • Page 5 CL420 / CL425 Only Split follower lock enables inside handle to retract latch and deadbolt simultaneously. Prevents accidental lock-ins. Deadbolt thrown by key to lock out code users after work hours. Key will retract the latchbolt giving access for admin functions https://codelocks.zohodesk.eu/portal/en/kb/articles/cl400-code-change-instructions...
  • Page 6 Double euro profile cylinder with 3 keys. Any euro profile cylinder may be used excluding thumb turn versions. On multiple door installations consideration should be given to having all cylinders keyed alike, with restricted key issue, for ease of management.   https://codelocks.zohodesk.eu/portal/en/kb/articles/cl400-code-change-instructions...
  • Page 7   CC-CL400-v1:0218   © 2019 Codelocks Ltd.  All rights reserved.   https://codelocks.zohodesk.eu/portal/en/kb/articles/cl400-code-change-instructions...
