3.4 VARIOUS MODELS AND TERMS
The Hemisphere can be installed on a variety of mounts, each of which includes a standard profile for attaching the Hemisphere
monitor. The following sections identify the various parts and controls on a standard Hemisphere transportable monitor, and available
mounts.
3.4.1 HEMISPHERE TRANSPORTABLE MONITOR
Valve Lever
Handle Lock
Knob
Swiveling Inlet
Pressure Gauge
©Copyright Task Force Tips LLC 2013-2020
Open/Close
Indicator
Rotation Lock
Release Lever
Serial Number
Monitor Release
Knob
Pressure Gauge
Cover
Hemisphere Transportable Monitor
Mounting Socket
Figure 3.4.1
6
Waterway
Rotation Crank
Double Ball Swivel
Synchronizer
Double Ball Swivel
Swiveling Outlet
Double Ball Swivel
Lock Knob
