3.3

USE WITH SALT WATER

Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of the
equipment may be shortened due to the effects of corrosion, and is not covered under warranty.
3.4

VARIOUS MODELS AND TERMS

The Monsoon Monitor is available in manual and electric remote controlled models.
Manual models are available with either handwheel control on both axis or a tiller bar model that uses a tiller bar to control horizontal
rotation.
Electric remote control models are available in a standard model (suitable for on top of pumpers), a Ladder model and a Platform model.
The Ladder or Platform models have a smaller swing radius and horizontal travel stops factory installed at 90° left and right (180° total).
The Monsoon Monitor c omes in manual and electric remote controlled models. Manual models are available wi on both axis or a tiller bar model that uses a tiller bar to control horizontal rotation. Electric remote control models are available in a standard model (suitable for on top of pumpers), a Ladder model and a Platform model. The Ladder or Platform model has a smaller swing radius and has horizontal travel stops factory installed at 90° left and right (180° total).trol
©Copyright Task Force Tips LLC 2004-2020
MODEL & SERIAL NUMBER
ON LABEL
PORT FOR
PRESSURE GAGE
ELEVATION TRAVEL
STOPS (3) PLACES
HORIZONTAL
ROTATION
HANDCRANK
INLET
Manual Handwheel Monsoon Monitor
TILLER HANDLE
Manual Tiller Bar Monsoon Monitor
HORIZONTAL ROTATION
TRAVEL STOPS
(6) PLACES
STRAIGHT AHEAD
REFERENCE MARK
Figure 3.4A
Figure 3.4B
8
ELEVATION
HANDWHEEL
OUTLET
TURNING
VANE
ELEVATION
HANDWHEEL
LOCKING
KNOB
