Dynamic DX Installation Manual page 54

DX System SLM Status
Status LED LED Flash
Flash Code Code
2
2
Likely Cause of Fault and Possible Action
3 Steering Fault
Cause: The Position Sense Pot is faulty or cannot
track the requested steering position.
Action: < Check the Pot Shaft is not slipping, or the
< Check the Pot For short and open circuits
< Ensure that the clutch is engaged and not
< Ensure that there is no excessive load on
< Check the servo motor connector and
Note: If this problem only occurs when large
steering movements are requested, the SLM`s motor
speed parameter may need to be recalibrated using
an HHP.
4 Lighting Fault
Cause: 1. A fault is detected in the lighting circuits
2. Indicator lights are flashing faster than
Action: < Check the lighting circuitry for shorts and
< Check side and indicator bulbs.
5
Clutch Released
Cause: The clutch switch is or has been in the
released position.
Action: < Re-engage the clutch if necessary and turn
< Check the servo motor connector and
< Check the operation of the clutch switch.
No. 60027, Issue 4. January 1998
Pot. Body turning.
between pins.
slipping.
the steering system.
wiring.
or the internal regulator (if fitted).
open circuits.
the DX System off then on.
wiring.
8 Diagnostics 51
