Dynamic DX Installation Manual page 41

Parameter
Lock Margin
Left Lock
0 V
Left Lock
Range 5 - 95 %
Accessed by : Dealer / User
HHP calibrated
Right Lock
Range 5 - 95 %
Accessed by : Dealer / User
HHP calibrated
Note:
The Left and Right Lock parameters must not both be above nor both be
below 50%. Typically one will be around 25% and the other around 75%, so that
the total will be around 100%.
7 Programming 38
Purpose
Physical Pot Limits
Actual Lock Limits
Pot Voltage Tolerance
Position
Sense
Pot
The ratio of the Position Sense Pot Wiper voltage to
the full pot voltage when the steering wheels are
moved as far left as is mechanically possible.
A physical limitation calibrated using the HHP - refer
to section 7.5.
The ratio of the Position Sense Pot Wiper voltage to
the full pot voltage when the steering wheels are
moved as far right as is mechanically possible.
A physical limitation calibrated using the HHP - refer
to section 7.5.
No. 60027, Issue 4. January 1998
Lock Margin
Right Lock
Min Pot End V
SP+
Max Pot End V
