5.4

SLM 21 Way Connector

5.4.1

21 Way Connector Pin Definitions

1 2
8 9
15 16
Note : Other pins unused.
5.4.2

21 Way Connector Wires and Terminations

To build a matching connector
To build a matching connector to fit to the 21 way connector, the parts are :
DX 21W Plug Housing
DX 21W Boot
DX Positronics Contact, FC114N2 (Lge)
DX Positronics Contact, FC116N2 (Med)
DX Positronics Contact, FC120N2 (Sml)
The DX Positronics Contacts are crimp terminals.
18
3 4 5 6
No. 60027, Issue 4. January 1998
Pin
7
1
14
2
3
4
5
6
7
8
9
14
15
16
Part/Order Number GCN 0796
Part/Order Number GCN 0795
Part/Order Number GCN 0793
Part/Order Number GCN 0797
Part/Order Number GCN 0794
Function
DXBUS -
Side Lights -
Left Indicator -
Right Indicator -
13.5 V
Hazard In
Hazard Out
Battery -
Steering Power +
Battery - (spare)
DXBUS +
Lighting +
5 Installation
