Dynamic DX Installation Manual page 43

Motor Speed
Range 20 - 5,100 ms
(0.02 - 5.1 sec.)
Accessed by : Dealer / User
HHP calibrated
Motor Damping Factor
Range 0 - 100 %
Accessed by : DCL
Restrict Fwd Spd 25 %
Restrict Fwd Spd 50 %
Restrict Fwd Spd 75 %
Restrict Fwd Spd 100 %
Restrict Rev Spd 25 %
Restrict Rev Spd 50 %
Restrict Rev Spd 75 %
Restrict Rev Spd 100 %
Accessed by : Dealer / User
HHP calibrated
Parameter
40 7 Programming
The time taken for the servo motor to travel the full
range from left lock to right lock, and visa
versa.
This is calibrated using the HHP.
The speed of response of the servo motor.
For slow motors this value should be low and for
fast motors the damping should be high.
Warning An unsuitably high or low value can
make the wheelchair unstable.
Range (%)
60 - 100
40 - 100
20 - 100
0 - 100
60 - 100
40 - 100
20 - 100
0 - 100
The maximum forward and reverse speeds for four
non-zero lock positions : 25, 50, 75 and 100 %
turning lock.
The physical restrictor plate fitted to the DX
Remote is calibrated with these parameters, using
the HHP.
If the DX Remote is replaced, these parameters
must be recalibrated.
Plate parameters are grouped and calibrated in one
operation of the HHP.
Purpose
No. 60027, Issue 4. January 1998
