5
Installation
5.1
Introduction
Installing a SLM requires the following steps:
1. Mounting the SLM
2. SLM Connection with the DX system
3. SLM 21 Way Connector
4. SLM Servo Connector
5. Programming the SLM related parameters
5.2
Mounting
Optimum mounting orientation
Fit the SLM with the top label facing up.
Unacceptable Mounting Orientation
Do not mount with connectors facing up.
Do not mount with the top label facing down.
Other orientations are acceptable.
10
No. 60027, Issue 4. January 1998
Refer Section 5.2
Refer Section 5.3
Refer Section 5.4
Refer Section 5.5
Refer Section 7.0
5 Installation
