SET COMMUNICATION:

This section defines the fundamental communication parameter of two Buses, NMEA 2000 and
PROFIBUS.
By Pressing the "Set Communication" button from the main window for SW67252 (Fig. 2) the
window "Set Communication" appears (Fig. 3).
The window is divided in two sections, one for the NMEA 2000 and the other for the PROFIBUS.
The means of the fields for "NMEA 2000" are:
In the field "Baud Rate" the data rate of the NMEA 2000 bus is defined;
In the field "TimeOut Data
reliable, on PROFIBUS side the data will be set to 0xFF;
If the field "Enable Peer to
PGN inserted in the "Receive Frames" section;
In the field "ID Device" the ID of the NMEA 2000 side is defined.
The means of the fields for "PROFIBUS Slave" are:
In the field "ID Device" the address for the PROFIBUS side is defined;
In the field "Baudrate" the data rate of the PROFIBUS side is defined (fixed to 'Auto
Baudrate');
If the field "Module for each NMEA 2000
inserted in a different Module, otherwise, if this field is not checked, a Module will contain up to
64 byte.
ADFweb.com Srl – IT31010 – Mareno – Treviso
(s)" a time is defined; when this time is elapsed and the data isn't
Peer" is checked, the gateway accepts all the ID that have the
Frame" is checked, when the "GSD File" is created, every NMEA 2000 frame will be
User Manual NMEA 2000 / PROFIBUS Slave
Document code: MN67252_ENG Revision 1.010
Figure 3: "Set Communication" window
