If you know the actual IP address of the device, you have to use this procedure:
Turn on the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Select update options (Firmware + Configuration);
Press the "Execute update
When all the operations are "OK" the device automatically goes at
Normal Mode.
At this point the configuration/firmware on the device is correctly update.
Note:
When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67235-A1
device.
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67235-A1 device.
Warning:
If Fig. 7 appears when you try to do the Update try these points before seeking
assistance:
Try to repeat the operations for the updating;
Try with another PC;
Try to restart the PC;
If you are using the program inside a Virtual Machine, try to use in the main Operating
System;
If you are using Windows Seven or Vista or 8, 10, make sure that you have the
administrator rights;
Take attention at Firewall lock;
Check the LAN settings.
In the case of HD67606-A1 you have to use the software "SW67606": www.adfweb.com\download\filefold\SW67235.zip.
ADFweb.com S.r.l.
firmware" button to start the upload;
User Manual DeviceNet Slave / CAN - Converter
Document code: MN67235_ENG Revision 2.000
Figure 7: "Protection" window
