Industrial Electronic Devices

User Manual

Revision 2.001

English

J1939 / Modbus TCP slave - Converter

(Order Code: HD67215-A1, HD67215-B2)

For Website information:

www.adfweb.com?Product=HD67215

For Price information:

www.adfweb.com?Price=HD67215-A1

www.adfweb.com?Price=HD67215-B2

Benefits and Main Features:

Triple Electrical isolation

Temperature range: -40°C/+85°C (-40°F/+185°F)

User Manual

ADFweb.com S.r.l.

User Manual J1939 / Modbus TCP slave

Document code: MN67215_ENG

Revision 2.001 Page 1 of 29

Page 1 of 29

For others Gateways / Bridges:

J1939 to Modbus

Need help?

Do you have a question about the HD67215-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67215-A1

Page 1 Revision 2.001 Page 1 of 29 Page 1 of 29 Industrial Electronic Devices User Manual Revision 2.001 English J1939 / Modbus TCP slave - Converter (Order Code: HD67215-A1, HD67215-B2) For Website information: www.adfweb.com?Product=HD67215 For Price information: www.adfweb.com?Price=HD67215-A1 For others Gateways / Bridges: www.adfweb.com?Price=HD67215-B2...
Page 2: Updated Documentation
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 2 of 29 Page 2 of 29 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: INDEX UPDATED DOCUMENTATION...
Page 3: Security Alert
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 3 of 29 Page 3 of 29 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4: Example Of Connection
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 4 of 29 Page 4 of 29 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l.
Page 5: Connection Scheme
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 5 of 29 Page 5 of 29 Industrial Electronic Devices CONNECTION SCHEME: Figure 2a: Connection scheme for HD67215-A1 ADFweb.com S.r.l.
Page 6 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 6 of 29 Page 6 of 29 Industrial Electronic Devices Figure 2b: Connection scheme for HD67215-B2 ADFweb.com S.r.l.
Page 7 Page 7 of 29 Industrial Electronic Devices CHARACTERISTICS: The HD67215-A1 and HD67215-B2 are J1939 / Modbus TCP slave Converters. They have the following characteristics: Triple isolation between J1939 - Power Supply, J1939 - Modbus TCP, Modbus TCP - Power Supply;...
Page 8: Table Of Contents
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67215-A1 HD67215-B2 Caution: Do not reverse the polarity power HD67215-A1 HD67215-B2 ADFweb.com S.r.l.
Page 9: Function Modes
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 9 of 29 Page 9 of 29 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’...
Page 10: Industrial Electronic Devices
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 10 of 29 Page 10 of 29 Industrial Electronic Devices LEDS: The device has got four/five LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below.
Page 11 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 11 of 29 Page 11 of 29 Industrial Electronic Devices J1939: To terminate the J1939 line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position. Cable characteristics: DC parameter: Impedance...
Page 12: Modbus Tcp
MODBUS TCP: The Modbus TCP connection must be made using Connector3 or Connector5 of HD67215-A1/B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps.
Page 13 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 13 of 29 Page 13 of 29 Industrial Electronic Devices USE OF COMPOSITOR SW67215: To configure the Converter, use the available software that runs with Windows called SW67215. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 14: New Configuration / Open Configuration
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 14 of 29 Page 14 of 29 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “J1939 / Modbus TCP slave - Converter”...
Page 15: Software Options
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 15 of 29 Page 15 of 29 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 16: Set Communication
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 16 of 29 Page 16 of 29 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, J1939 and Modbus TCP By Pressing the “Set Communication”...
Page 17 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 17 of 29 Page 17 of 29 Industrial Electronic Devices The meaning of the fields of “Modbus TCP Slave” is: In the fields “IP ADDRESS” insert the IP address that you want to give to the Converter; In the fields “SUBNET Mask”...
Page 18 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 18 of 29 Page 18 of 29 Industrial Electronic Devices RECEIVE J1939: By pressing the “Receive J1939” button from the main window of SW67215 (Fig. 2) the window “Receive J1939 Frames” appears (Fig. 4). The meaning of the fields of the table are: In the field “Data...
Page 19 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 19 of 29 Page 19 of 29 Industrial Electronic Devices DEFINE RECEIVE J1939 By pressing the “Define J1939” button, near “Receive J1939” from the main window of SW67215 (Fig. 2) the window “Define Receive J1939”...
Page 20 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 20 of 29 Page 20 of 29 Industrial Electronic Devices TRANSMIT J1939 By pressing the “Transmit J1939” button from the main window of SW67215 (Fig. 2) the window “Transmit J1939 Frames” appears (Fig. The meaning of the fields of the table are: In the field “Priority”...
Page 21 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 21 of 29 Page 21 of 29 Industrial Electronic Devices DEFINE TRANSMIT J1939 By pressing the “Define J1939” button, near “Transmit J1939” from the main window of SW67215 (Fig. 2) the window “Define Transmit J1939”...
Page 22 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 22 of 29 Page 22 of 29 Industrial Electronic Devices ENABLE REMOTE REQUEST (RTR) If the field “Enable Remote Request (RTR)” that is present in the section “Set Communication” is checked, you need to define the Modbus registers that are used to compose the Remote Request.
Page 23: Update Device
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 23 of 29 Page 23 of 29 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device;...
Page 24 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 24 of 29 Page 24 of 29 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67215 device. Warning: If Fig.
Page 25: Mechanical Dimensions
User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 25 of 29 Page 25 of 29 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 11a: Mechanical dimensions scheme for HD67215-A1 ADFweb.com S.r.l.
Page 26 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 26 of 29 Page 26 of 29 Industrial Electronic Devices Figure 11b: Mechanical dimensions scheme for HD67215-B2 ADFweb.com S.r.l.
Page 27: Ordering Informations
A: 1M, 35mm DIN Rail mounting B: 4M, 35mm DIN Rail mounting Device Family HD67215: J1939 / Modbus TCP slave - Converter Order Code: HD67215-A1 J1939 / Modbus TCP slave - Converter Order Code: HD67215-B2 J1939 / Modbus TCP slave - Converter...
Page 28 User Manual J1939 / Modbus TCP slave Document code: MN67215_ENG Revision 2.001 Page 28 of 29 Page 28 of 29 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 29 Industrial Electronic Devices ADFweb.com S.r.l.
