Industrial Electronic Devices
User Manual
Revision 2.100
English
M-Bus Master / Modbus TCP Slave - Converter
(Order Code:
HD67044-B2-20, HD67044-B2-40, HD67044-
B2-80, HD67044-B2-160, HD67044-B2-250)
For Website information:
www.adfweb.com?Product=HD67044-B2
For Price information:
www.adfweb.com?Price=HD67044-B2-20
www.adfweb.com?Price=HD67044-B2-40
www.adfweb.com?Price=HD67044-B2-80
www.adfweb.com?Price=HD67044-B2-160
www.adfweb.com?Price=HD67044-B2-250
Benefits and Main Features:
Very easy to configure
Up to 250 standard M-Bus devices connected to the Converter
Power Supply 15...21V AC or 18...35V DC
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual M-Bus Master / Modbus TCP Slave
Document code: MN67044_ENG
For other M-Bus products see also the following link:
Converter - M-Bus /
www.adfweb.com?Product=HD67021
www.adfweb.com?Product=HD67022
www.adfweb.com?Product=HD67030
Analyzer & Scanner M-Bus
www.adfweb.com?Product=HD67031
M-Bus – Repeater - Isolator
www.adfweb.com?Product=HD67032
Converter - M-Bus Master/ Modbus Slave
www.adfweb.com?Product=HD67029M-232
www.adfweb.com?Product=HD67029M-485
M-Bus Master / PROFIBUS Slave - Converter
www.adfweb.com?Product=HD67053M
M-Bus – Concentrator - Datalogger
www.adfweb.com?Product=HD67054M
M-Bus Slave / Modbus Master - Converter
www.adfweb.com?Product=HD67059M-232
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
Revision 2.100
Page 1 of 37
(RS232)
(RS485)
(Ethernet)
(on RS232)
(on RS485)
Advertisement
Table of Contents
Related Manuals for ADF Web HD67044- B2-80
Summary of Contents for ADF Web HD67044- B2-80
- Page 1 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 1 of 37 Industrial Electronic Devices User Manual Revision 2.100 English M-Bus Master / Modbus TCP Slave - Converter (Order Code: HD67044-B2-20, HD67044-B2-40, HD67044- B2-80, HD67044-B2-160, HD67044-B2-250) For Website information: www.adfweb.com?Product=HD67044-B2 For other M-Bus products see also the following link:...
-
Page 2: Table Of Contents
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 2 of 37 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page INDEX Updated... -
Page 3: Security Alert
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 3 of 37 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 4 of 37 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 5 of 37 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67044-B2-xxx ADFweb.com S.r.l. -
Page 6: Characteristics
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 6 of 37 Industrial Electronic Devices CHARACTERISTICS: The HD67044-B2-xxx is a M-Bus Master / Modbus TCP Slave Converter. It allows the following characteristics: Electrical isolation between Ethernet and M-Bus; Mountable on 35mm Rail DIN;... -
Page 7: Power Supply
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 7 of 37 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 15…21V AC and 18…35V DC. The consumption depends to the code of the device. For more details see the two tables below. -
Page 8: Function Modes
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 8 of 37 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... -
Page 9: Leds
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 9 of 37 Industrial Electronic Devices LEDS: The device has got two LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Modbus Tcp
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 10 of 37 Industrial Electronic Devices MODBUS TCP : The Modbus TCP connection must be made using Connector3 of HD67044-B2 with at least a Category 5E cable. -
Page 11: Use Of Compositor Sw67044
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 11 of 37 Industrial Electronic Devices USE OF COMPOSITOR SW67044: To configure the Converter, use the available software that runs with Windows called SW67044. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 12: New Project / Open Project
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 12 of 37 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “M-Bus Master / Modbus TCP Slave - Converter”... -
Page 13: Software Options
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 13 of 37 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 14: Set Communication
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 14 of 37 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two Buses, Modbus and M-Bus. By Pressing the “Set Communication” button from the main window for SW67044 (Fig. 2) the window “Set Communication”... - Page 15 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 15 of 37 Industrial Electronic Devices In the field “Node State value when slave device is not present” it is possible to insert the value to assign to the “Node State” register when the converter doesn’t find the interrogated M-Bus slave;...
-
Page 16: M-Bus
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 16 of 37 Industrial Electronic Devices M-BUS By Pressing the “M-Bus” button from the main window for SW67044 (Fig. 2) the window “M-Bus Network” appears (Fig. 4). In the section “Nodes”... - Page 17 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 17 of 37 Industrial Electronic Devices If the field “Send SND_NKE” is checked, the Converter send the “SND_NKE” frame to start the communication. In the field “Send Reset App.”...
- Page 18 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 18 of 37 Industrial Electronic Devices ECTION ARIABLES Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable Variable”...
- Page 19 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 19 of 37 Industrial Electronic Devices In the field “Tariff” if it is necessary it is possible to insert the value of the tariff of that variable. The Tariff is used for indicates from which device the data come;...
- Page 20 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 20 of 37 Industrial Electronic Devices SECTION VARIABLES (BY POSITION): Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable Variable”...
- Page 21 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 21 of 37 Industrial Electronic Devices If the field “Force Integer 32” is checked the Converter maps the variables with a dimension <32 bit in two consecutive Modbus registers as a 32 bit variables;...
- Page 22 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 22 of 37 Industrial Electronic Devices Example: 0x68 - Start Byte 0xBD - L Fied 0xBD - L Field 0x68 - Start Byte 0x08 - C Field 0x02 - A Field 0x72 - CI Field Identification Number (or Secondary Address) put in the...
- Page 23 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 23 of 37 Industrial Electronic Devices ASTE AND ELETE TEMS By pressing the right button of the mouse over an item (Variable or Node) it is possible to Copy, Paste and Delete. It is possible to Copy a variable from a Node and copy it to another Node, or copy a Variable from a project and paste in another one.
- Page 24 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 24 of 37 Industrial Electronic Devices Possible choices for the fields used to create a variable: Type of Data: Function Field: |_Energy (Wh) |_Instantaneous Value |_Energy (J) |_Minimum Value |_Volume (m |_Maximum Value...
- Page 25 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 25 of 37 Industrial Electronic Devices VIFE: |_ Period of tariff months(s) |_ Not Selected |_ Period of tariff year(s) |_ Credit of the nominal local legal currency units |_ dimensionless/ no VIF |_ Debit of the nominal local legal currency units |_ Volts...
- Page 26 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 26 of 37 Industrial Electronic Devices |_ per minute |_ Duration of limit exceed |_ per hour |_ Duration of first/last |_ per day |_ Date(/time) of first/last begin/end |_ per week |_ Multiplicative currection factor |_ per month...
- Page 27 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 27 of 37 Industrial Electronic Devices Swap Identification: This field is used for select the Swap mode of Identification Number. At the moment there are these possibilities: None;...
- Page 28 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 28 of 37 Industrial Electronic Devices To know the meaning of value read in the “Modbus Re Scale” field, you must follow this table (x = Value read in Modbus Re Scale): Description Range Coding Range...
- Page 29 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 29 of 37 Industrial Electronic Devices Data type F: Min (0 … 59); Hour (0 … 23); Day (1 … 31); Month (1 … 12); Year (0 … 99); Time Invalid (0=Valid, 1=Invalid);...
-
Page 30: Manufacturer Specific Data
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 30 of 37 Industrial Electronic Devices MANUFACTURER SPECIFIC DATA Using this function is possible to save into Modbus registers the part of M-Bus frame that is coded like Manufacturer Specific Data. Usually these data are at the end of the frame and after a DIF byte with the value 0x0F of 0x1F. -
Page 31: Update Device
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 31 of 37 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;... - Page 32 User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 32 of 37 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67044 device. Warning: If Fig.
-
Page 33: Scan & Decode Function
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 33 of 37 Industrial Electronic Devices SCAN & DECODE FUNCTION: “SCAN & DECODE” functions are integrated in the configurator software SW67044. It is possible to access to these functions by simple click on the “... -
Page 34: Mechanical Dimensions
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 34 of 37 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7: Mechanical dimensions scheme for HD67044-B2-xxx ADFweb.com S.r.l. -
Page 35: Order Codes
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 35 of 37 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67044 – B 2 – xxx Maximum number of slaves supported 20: up to 20 standard slaves (1.5mA consumption) connected to M-Bus 40: up to 40 standard slaves (1.5mA consumption) connected to M-Bus... -
Page 36: Disclaimer
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 36 of 37 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 37: Warranties And Technical Support
User Manual M-Bus Master / Modbus TCP Slave Document code: MN67044_ENG Revision 2.100 Page 37 of 37 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
