NTI VOPEX PS/2 KVM SPLITTER

INTRODUCTION

This VOPEX allows 1 IBM compatible CPU to support multiple users (either 2 or 4, depending on the VOPEX model). The PS/2
devices (keyboards and mice) of many different manufacturers can be plugged into the VOPEX when powering up. Also, any
combination of devices will work. (e.g. a mouse on port 2, keyboards on ports 3 and 4). Hot plugging devices at any time is fully
supported with the possible exceptions listed in "SPECIAL MOUSE CONSIDERATIONS" (page 3).
Features
•
Multiple users can enter data from multiple locations
•
Compatible with all PS/2 style PCs, RS6000, SGI, and HP9000
•
Compatible with most PS/2 mice
•
Keyboards and mice are hot-pluggable
•
Interconnect NTI switches and splitters for complex applications
•
Supports 1920 x 1200 resolution at 150MHz bandwidth
Option: VOPEX wtih stereo audio support- connect an audio source and up to 4 self-powered-stereo audio speakers-
Order VOPEX-4KVIMA-A (4-port) or VOPEX-2KVIMA-A (2-Port)

MATERIALS

Materials Supplied with this kit
•
VOPEX 2/4KVIM-A 2 or 4 Port PS/2 KVM Splitter
•
110 or 220VAC at 50 or 60Hz-5VDC/2A AC Adapter
•
Line cord, country specific
•
A set of cables connecting the VOPEX to the IBM compatible CPU:
•
VEXT-3
•
VVKINT-3-MM
•
SA-3-MM
Optional Materials
•
A cable for each device to be connected to the VOPEX. The maximum length of these cables is 100 feet.
• VVKINT-xx -PS/2 Keyboard or Mouse extension cable (3, 6, 10, 15 and 25 foot lengths available)
• VVKEXT-xx -PS/2 Keyboard or Mouse extension cable (35, 50, 75, and 100 foot lengths available)
• VEXT-xx
-VGA video extension cable (3,6,10,15,25,35,50,75 and 100 foot lengths available)
• SA-xx-MF
- Audio Extension cable (3,6,12,14, 25, and 50 foot lengths available)
where: xx is the length of the cable in feet, and
MM indicates male-to-male connectors.
Cables can be purchased from Network Technologies Inc by calling (330) 562-7070, or (800) RGB-TECH (800-742-8324), or by
visiting our website at http://www.networktechinc.com.
Note: Any internal building wiring must be performed by a local licensed electrician and comply with the National
Electrical Code (NEC) requirements.
-Connects the Video port of the CPU to the VOPEX
-Connects the PS/2 keyboard and mouse ports of the CPU to the
VOPEX
-Connects the Audio port of the CPU to the VOPEX (models with audio
support only)
