Summary of Contents for NTI VOPEX-DVI4K-2
- Page 1 ® VOPEX Series VOPEX-DVI4K-2 2 Port 4K DVI/HDMI Video Splitter Installation and Operation Manual VOPEX-DVI4K-2 MAN245 Rev Date 7/16/2015...
-
Page 2: Table Of Contents
TRADEMARK VOPEX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 2009-2015 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. -
Page 3: Introduction
INTRODUCTION The VOPEX-DVI4K-2 2-Port 4K DVI/HDMI video splitter enables two single-link digital DVI displays or two 4K HDMI displays (with appropriate cables or adapters) to be driven by a single digital DVI or HDMI source (PC, DVD player, Satellite receiver, etc.) with no loss of signal. -
Page 4: Materials
NTI 4K 2-Port DVI Video Splitter MATERIALS Materials Supplied with this kit: • NTI VOPEX-DVI4K-2 DVI/HDMI Video Splitter • 100VAC to 240VAC at 50 or 60Hz-5VDC/3.0A AC Adapter • DVI-IS-3-MM 3 foot DVI-I single link video interface cable • This owners manual Materials Not Supplied, but REQUIRED: DVI interface cables ARE REQUIRED but not supplied. -
Page 5: Installation
NTI 4K 2-Port DVI Video Splitter INSTALLATION The VOPEX is a Plug-and-Play device with no special configuration settings and easy installation steps: Before connecting the VOPEX to the video source, make sure the video source and the monitor(s) are turned OFF. - Page 6 NTI 4K 2-Port DVI Video Splitter 3. Connect a monitor to a DVI female port labeled “DVI-D Video Out x” on the rear panel of the VOPEX using a male-to-male DVI cable. Note: Some monitors need to have their video input type set manually. In this case, select “Digital DVI”...
- Page 7 NTI 4K 2-Port DVI Video Splitter 4. Plug the 5VDC AC adapter into the power jack on the rear panel. 5. Power up the VOPEX. 6. Power up the display device(s). 7. Power up the video source. The video from the source should now be displayed on both connected display devices.
-
Page 8: Cascading
VOPEXs in a cascaded configuration (example below). Using additional DVI-IS-xx-MM cables, connect the DVI Video Out ports of a master VOPEX unit (master is connected to the video source) to the DVI Video In ports of additional VOPEX-DVI4K-2 (shown as “Slave Unit #1” and “Slave Unit #2” below). -
Page 9: Technical Specifications
NTI 4K 2-Port DVI Video Splitter TECHNICAL SPECIFICATIONS VIDEO Video Source Any with DVI or HDMI output (Computer, Satellite Receiver, DVD player,etc) Video Connections Female DVI-I Single Link Maximum Pixel Clock Rate 340 MHz Supported Standard Resolution Up to 4K/3840x2160@30Hz or 1080p/1920x1200@60Hz.
