PARTS SUPPLIED

• Hood body, with stainless steel baffle filter and halogen light bulbs and incandescent lamp already installed
• Two telescopic duct covers and support bracket
• Hardware Packet:
- 24x53 T1T2 "L" Male monkey spanner (1 piece)
- 3.5X9.5 screws to fix the internal blower (4 pieces)
- 3.5X9.5 screws to fix the duct cover (4 pieces)
- 3.5X9.5 screws to fix the 8" collar plastic round transition duct cover (4 pieces)
- 4x8 screws to fix the external blower wiring box (4 pieces)
- M4 nut for the grounding screw to connect the grounding screw to the external blower (3 pieces)
- toothed washer to connect the grounding screw to the external blower (3 pieces)
• Wall mounting brackets (1 piece)
• 8" Collar (1 piece)
• Plastic round transition with damper (1 piece)
• Cover round transition (1 piece)
• Rectangular transition air discharge + flange
• External blower wiring box with wires
• Template (1 piece)
• Use, Care and Installation Guide
• Warranty

PARTS NOT SUPPLIED

• Duct, conduit and all tools required for installation.
• Internal blower
To be used only in case of Internal blower installation.
• External blower
To be used only in case of External blower installation.
• Front panel.
CAUTION
To reduce the risk of fire and electric shock, install this rangehood only with integral blowers mod. EBI-600B
manufactured by ZEPHYR or with external blowers mod. CBE-1000, manufactured by ZEPHYR.
And with front panels mod. CPC-0012 (42" SS); mod. CPC-0112 (42" Brass); mod. CPC-0018 (48" SS); mod. CPC-
0118 (48" Brass); mod. CPC-0015 (54" SS); mod. CPC-0115 (54" Brass).
WARNING
To Reduce The Risk Of Fire, Electric Shock, And Injury To Persons, this rangehood Must Be Installed With Front
Panels That Are Marked (on their cartons) To Indicate The Suitability With This Model. Other Front Panels Cannot
Be Substituted.
7
