MODEL: CTP-ExxS
1 - Hood
2 - Baffle Filters
4 - G U-10, 120V 50 W, halogen bulbs
2 - Utensil Rails
2 - Telescopic Duct Covers
4 - Telescopic Rods Sets
4 - Angle Bra ckets (27 3/8")
4 - Angle Bra ckets (35 3/8")
1 - Ceiling MountingBra cket
1 - Internal Flange
1 - Motor Housing
1 - HARDWARE PACKET
4 - Couplers
4 - Anchors
4 - 2" Wood Screws
4 - 2 1/2" Wood Screws
4 - 1/2" Washers
26 - 1/2" Self Tapping Screws
4 - 1/2" Screws 5x15mm
4 - 5mm Internal Diameter Washers
4 - Adhesive Fasteners
4 - Cable Ties
1 - SMALL HARDWARE PACKET
10 - Short Set Screws
12 - Medium Set Screws
1 - Tool
1 - HARDWARE PACKET FOR ELECTRICAL CONNECTION AND EXTERNAL BLOWER CONNECTION
1 - External Flange with Attached 8" Collar
1 - Junction Box with Wires
1 - External Blower Wiring B ox with Wires
12 - 1/2" Self Tapping Screws
1 - Electrical Connection Wiring
12 - 4mm Internal Diameter Washers
NO DUCTING IS PROVIDED
EXTERNAL AND INTERNAL BLOWER SOLD SEPARATELY
Make sure to remove the protective film off of the hood before installation in order to make removal of the film
easier. Be careful not to scratc h the stainless steel while installing.
