s s I e u C u a
After installation, the unit 1. The power source is not turned ON.
doesn't work?
2. The power line and the cable locking connector is
not connecting properly.
3. The switch board and control board wirings
are disconnected.
4. On the switch board, Black/White wire of White
wire is disconnected.
5. The switch board or control board is defective.
1. The motor is defective, possible seized.
Light works, but motor is
not turning.
2. The thermally protected system detects if the motor
is too hot to operate and shuts the motor down.
3. Damaged capacitor.
1. The motor is not secure in place.
The unit is vibrating.
2. Damaged blower wheel/makes noise.
3. The hood is not secured in place.
1. Defective halogen bulb.
The motor is working,
but the lights are not.
2. T he light bulb is loose.
1. T he hood might be hanging to high from the
The hood is not venting
cook top.
out properly.
2. The wind from the opened windows or opened
doors in the surrounding area are affecting the
ventilation of the hood.
3. Blocking in the duct opening or ductwork.
4. T he direction of duct opening is against the wind.
5. Using the wrong size of ducting.
1. Baffle filter is loose.
Filter is vibrating.
1. Control board needs to be reset.
After hood has been
installed for a period of
time, it stopped working.
1. Defective control board.
e s
19
www.zephyronline.com
W h t a o t o d
1. Make sure the circuit breaker and the unit's
power is ON.
2. Check the power connection with the unit is
connected properly.
3. Make sure the wirings between the switch
board and control board are connected properly.
4. Make sure the Black/White wire or White wire
connects properly.
5. Change the switch board or control board.
1. Change the motor.
2. The motor will function properly after the
thermally protected system cool down.
3. Change the capacitor.
1. Tighten the motor in place.
2. Change the motor.
3. Check the installation of the hood.
1. Change the halogen bulb.
2. T ighten the light bulb.
1. Adjust the distance between the cook top
and the bottom of the hood within 24" and
32" range.
2. Close all the windows and doors to eliminate the
outside wind flow.
3. Remove all the blocking from the duct work or
duct opening.
4. Adjust the duct opening direction.
5. Change the ducting to at least 6" or higher
for the internal blower and 8" or higher for the
external blower.
1. Remove filter and reinstall it or c hange the
baffle filter.
1. Turn circuit breaker which controls the hood off
for at least 15 minutes.
Turn it back on and this should fix the problem.
1. Replace control board.
