This document supplements the following manuals:
- Instructions and warnings for IR-12/IR-24
80381_MSW_IR-12/IR-24_04-2015_ENG
IR-12 / IR-24
MULTICHANNEL POWER CONTROLLER
CONFIGURATION AND
PROGRAMMING MANUAL
Software version: 1.0x
code: 80381 - 04-2015 - ENG
ATTENTION!
This manual is an integral part of the product,
and must always be available to operators.
This manual must always accompany the pro-
duct, including if it is transferred to another user.
Installation and/or maintenance workers MUST
read this manual and scrupulously follow all of the in-
structions in it and in its attachments. GEFRAN will not
be liable for damage to persons and/or property, or to
the product itself, if the following terms and conditions
are disregarded.
The Customer is obligated to respect trade
secrets. Therefore, this manual and its attachments
may not be tampered with, changed, reproduced,
or transferred to third parties without GEFRAN's
authorization.
1
Advertisement
Table of Contents
Related Manuals for gefran IR-12
Summary of Contents for gefran IR-12
- Page 1 Installation and/or maintenance workers MUST read this manual and scrupulously follow all of the in- structions in it and in its attachments. GEFRAN will not be liable for damage to persons and/or property, or to the product itself, if the following terms and conditions are disregarded.
- Page 2 80381_MSW_IR-12/IR-24_04-2015_ENG...
-
Page 3: Table Of Contents
TABLE OF CONTENTS AND SUMMARIES OUTPUTS ................. 11 TABLE OF CONTENTS AND SUMMARIES ......3 ENABLING SSR OUTPUT CHANNELS ....... 11 ASSIGNMENT OF DIGITAL OUTPUTS ....... 11 INTRODUCTION ..............4 FIELD OF USE ...............4 CONTROLS ..............12 CHARACTERISTICS OF PERSONNEL ......4 COMPENSATION OF LINE VOLTAGE ......14 STRUCTURE OF THIS MANUAL ........5 CONTROLLING POWER ..........15 CONTROLLING THE DEVICE VIA SERIAL .......6... -
Page 4: Introduction
Since it is impossible to foresee all of the installations and environments in which the instrument may be applied, adequate technical preparation and complete knowledge of the instrument’s potentials are necessary. GEFRAN declines all liability if rules for correct installation, configuration, and/or programming are disregarded, as well as all liability for systems upline and/or downline of the instrument. -
Page 5: Structure Of This Manual
This manual was originally written in ITALIAN. Therefore, in case of inconsistencies or doubts, request the original manual or explanations from GEFRAN. The instructions in this manual do not replace the safety instructions and the technical data for installation, configuration and programming applied directly to the product or the rules of common sense and safety regulations in effect in the country of installation. -
Page 6: Controlling The Device Via Serial
- serial speed = 19200 bit/s - serial parity = none You can install a maximum of 99 IR-12/IR-24 modules in a serial network, with node address selectable from “01” to “99”. Settings Baud Select baud rate Baud rate table... -
Page 7: Inputs
INPUTS LINE VOLTAGE VALUE The RMS voltage values of each phase are shown in parameters Volt.Lp (with p = phase from 1 to 3). A voltage presence check is active for each phase; the check switches off the module if the voltage value is incorrect The S.General parameter contains information on line voltage status, including network frequency Reading status Volt.L1... -
Page 8: Digital Inputs
DIGITAL INPUTS Four digital inputs are always present. Each input can perform different functions based on the setting of the following parameters: Settings In.1 Table of digital input functions Digital input 1 function No function (input disabled) In.2 Digital input 2 function General alarm reset Enable/Disable loads of L1 phase In.3... -
Page 9: Alarms
ALARMS ALARM: thermal protection Each IR-12/IR-24 module has two temperature sensors for the internal heat sinks. The temperature values are show in variables Temp.1 and Temp.2 The overtemperature alarm shown in S.Alarm trips when at least one of the temperatures exceeds a set limit. -
Page 10: Alarms Fuse_Open, Ssr_Short
ALARMS FUSE_OPEN, SSR_SHORT and LOAD_OPEN Diagnostics is active to check correct functioning of the process: - FUSE_OPEN alarm: trips at opening of internal fuse - LOAD_OPEN alarm: trips when load is interrupted or disconnected - SSR_SHORT alarm: trips when the solid status relay is in short circuit NOTE1 : In PA_mode, the diagnostic Alarms Load-Open and Fuse_open are detected for SCR power firing higher than 40%. -
Page 11: Outputs
OUTPUTS ENABLING SSR OUTPUT CHANNELS The 24 output channels can be enabled by means of parameters En.Lp (with p = phase from 1 to 3). Enabling of the channels is saved in eeprom to maintain the last saved status at the next power-up. This saving can be disabled by means of the Option parameter. -
Page 12: Controls
CONTROLS In manual power control mode you can drive the outputs with a settable power percentage defined by: M.P.Lp.o (with p = phase from 1 to 3, o = output from 1 to 8). You can disable the saving of these parameters in EEPROM by means of the Option parameter (for example, in case of repeated changes by a PLC). - Page 13 Reading status Percentage of modulation of Power setpoint % of output 1 Out.P.L1.1 Pw.L1.1 output 1 phase L1 phase L1 Power setpoint % of output 2 Percentage of modulation of Pw.L1.2 Out.P.L1.2 phase L1 output 2 phase L1 Power setpoint % of output 3 Pw.L1.3 Percentage of modulation of Out.P.L1.3...
-
Page 14: Compensation Of Line Voltage
COMPENSATION OF LINE VOLTAGE This function lets you correct supplied power based on reference line voltage Volt.Nom.Lp (with p = phase from 1 to 3). The function can be activated / deactivated with the Option parameter. Correct compensation status is shown in the status of each S.Out.Lp.o (with p = phase from 1 to 3, o = output from 1 to 8). Settings Volt.Nom.L1 230.0... -
Page 15: Controlling Power
CONTROLLING POWER SSR COMMAND MODE The following power control modes are settable with the Firing.t parameter: - Optimized BF: modulation by means of changing the number of conduction cycles with zero crossing firing at each full wave with optimum distribution of active channels (refresh time equals 100 half waves: 2.00 s at 50Hz, 1.66 s at 60Hz) to minimize current draw peaks - BF modulation by means of changing the number of conduction cycles with zero crossing firing at full wave... -
Page 16: Hw/Sw Information
HW/SW INFORMATION You can identify the HW/SW on the controller and check their operation by means of the following information registers Software version code mtmID 5000 Manufact - Trade Mark (Gefran) Manufacturer’s name deviceID Device ID (IR-12/IR-24 module) Device product... -
Page 17: Appendix
APPENDIX PARAMETERS Assigned Parameter definition Notes value CONTROLLING THE DEVICE VIA SERIAL Baud Select baud rate Select parity Device identification code Value acquired by rotary switches (tens+units) LINE VOLTAGE VALUE Volt.L1 Voltmeter input value phase L1 Volt.L2 Voltmeter input value phase L2 Volt.L3 Voltmeter input value phase L3 S.General... - Page 18 ALARM: FUSE_OPEN, SSR_SHORT and LOAD _OPEN S.Alarm Alarms status S.Out.L1.1 Status of output 1 phase L1 S.Out.L1.2 Status of output 2 phase L1 S.Out.L1.3 Status of output 3 phase L1 S.Out.L1.4 Status of output 4 phase L1 S.Out.L1.5 Status of output 5 phase L1 S.Out.L1.6 Status of output 6 phase L1 S.Out.L1.7...
- Page 19 ASSIGNMENT OF DIGITAL OUTPUTS Out.1 Assignment digital output OUT 1 Out.2 Assignment digital output OUT 2 Out.3 Assignment digital output OUT 3 Out.4 Assignment digital output OUT 4 S.IO Digital I/O states CONTROL Option Device option Length of softstart ramp in manual M.Ramp.tm mode M.P.L1.1...
- Page 20 M.P.L3.5 Manual power of output 5 phase L3 M.P.L3.6 Manual power of output 6 phase L3 M.P.L3.7 Manual power of output 7 phase L3 M.P.L3.8 Manual power of output 8 phase L3 COMPENSATION OF LINE VOLTAGE Volt.Nom.L1 Rated voltage phase L1 Volt.Nom.L2 Rated voltage phase L2 Volt.Nom.L3...
- Page 21 Trigger type BF.Cycles Minimum number of cycles of BF mode LOAD TYPE Load.t Load type HW/SW INFORMATION Software version code mtmID Manufact - Trade Mark (Gefran) deviceID Device ID (IR-12/IR-24 Module) Model Hardware configuration code S.General General status S.Alarm Alarms status S.IO...
- Page 22 GEFRAN spa via Sebina, 74 - 25050 Provaglio d’Iseo (BS) Italy Tel. +39 0309888.1 - Fax +39 0309839063 info@gefran.com - http://www.gefran.com...
