80380A_MHW_IR-12/IR-24_11-2015_ENG
IR-12 / IR-24
MULTICHANNEL POWER CONTROLLER
INDEX
2
4
GRAPHIC SYMBOLS
INSTALLATION AND
OPERATION MANUAL
code
80380A - 11/2015 -
3
Electrical connections
3.1
Power connections
3.2
Functions of indicator leds
3.3
Control connectors
3.4
Connection example: power section
4
Installation of serial network
4.1
"AUTOBAUD SERIAL" sequence
5
Technical Characteristics
6
Technical-Commercial information
6.1
Accessories
Indicates a suggestion based on the experience of
GEFRAN's Technical Personnel that could be
especially useful under certain circumstances.
Indicates a reference to Detailed Technical
Documents available on the GEFRAN website
www.gefran.com.
ENG
13
20
22
24
1
Advertisement
Table of Contents
Related Manuals for gefran IR-12
Summary of Contents for gefran IR-12
- Page 1 Indicates a suggestion based on the experience of Indicates contents of sections, general instructions, notes, and GEFRAN’s Technical Personnel that could be other points to which the reader’s attention needs to be called. especially useful under certain circumstances.
-
Page 2: General Description
EMC emission and consequently evoiding to use expensive and space consuming EMC filters. The section contains general information and IR-12/IR-24 is equipped with a local brain able to provide a warnings to be read before installing, configuring and continuos monitoring of the power percentage provided by the using the controller. -
Page 3: Preliminary Instructions
See paragraph 2.1 “ Dimensions and mounting” before installing the IR-12/IR-24 on the machine/host system control panel. To configure the PC use the SW Gefran GF-Express kit and the relative connection cable. For the order code, see Section: “Technical-Commercial Information”. -
Page 4: Electrical Power Supply
2 • INSTALLATION AND CONNECTION This section contains the instructions needed for ecommenDations for orrect nstallation correct installation of IR-12/IR-24 controllers on the for PurPoses of machine/host system control panel and for correct 2.3.1 Instrument power supply connection of the power supply, inputs, outputs and •... - Page 5 GEFRAN S.p.A. assumes no liability for any da- • dissipation of device thermic power with effects on installation room temperature. mage to persons or property deriving from tam- • thermal power dissipation with limits on installation room tem- pering, from incorrect or improper use, or from perature.
- Page 6 INSULATION DIAGRAM 80380A_MHW_IR-12/IR-24_11-2015_ENG...
- Page 7 Fastening can be done with five screw M6. See figures 1 and 2. All dimensions are expressed in mm. Figure 1a - Dimensions of Models IR-24 and IR-12 with MODBUS RTU communication Figure 1b - Dimensions of Models IR-24 and IR-12 with Fieldbus communication...
-
Page 8: Template Dimensions
TEMPLATE DIMENSIONS 2.4.1 Figure 2 nstallation Attention: respect the minimum distances shown in figure 3 to provide adequate air circulation. Figure 3 80380A_MHW_IR-12/IR-24_11-2015_ENG... - Page 9 DescriPtion Figure 4a - Frontal view of IR-24 and IR-12 with MODBUS communication 1. Diagnostics LED 7. Line power terminals 400-480VAC (3F + N, Ground) 2. Modbus address (Rotary switch) 8. Fuse holders with protection fuses (24 for IR24, 12 for IR12) 3.
- Page 10 Figure 4b - Frontal View of IR-24 and IR-12 with Fieldbus PROFINET 1. Diagnostics Leds 7. Line power terminals 400-480VAC (3F + N, Earth) 2. Ethernet port ETH0, ETH1 8. Fuse holders with protection fuses (24 for IR24, 12 for IR12) 3.
- Page 11 Figure 5 Fan suppy plug connector Removable Fan Unit Fan Unit fixing screws NOTE: For IR-12 models, the fan Unit is provided with only one fan. 80380A_MHW_IR-12/IR-24_11-2015_ENG...
-
Page 12: Periodic Cleaning
PERIODIC CLEANING Every 6-12 months (depending on the dust level of the installation) blow a compressed air jet downward through the upper rectangular cooling grilles (on the side opposite the fan). This will clean the internal heat dissipater and the cooling fan. IN CASE OF OVERHEAT ALARM ATTENTION: Before and during the inspection/maintenance cut power to the fan controller and verify that the system is... -
Page 13: Electrical Connections
3 • ELECTRICAL CONNECTIONS ower connections RECOMMENDED WIRE GAUGES Table 4 TERMINAL / MODEL CABLE SECTION TERMINAL TYPE TIGHTENING TORQUE /TOOL CONNECTOR 25-35 mm² 4 ...4,2 Nm / IR24, IR12 L1, L2, L3 Tip / Stripped wire 4-2 AWG Flat-head screwdriver 16-25 mm²... - Page 14 ontrol connector 3.3.1 CONNECTOR X4 - DIGITAL I/O Figure 6 CONNECTOR X4 (CONTROL) Table 7 0,2 - 2,5mm 24-14AWG 0,25 - 2,5mm 23-14AWG Connection schema X4 - Connector Digital I/O Figure 7 Table 8 NAME DESCRIPTION Digital input I1 Digital input I2 Digital input I3 Digital input I4 Digital output O1...
- Page 15 3.3.2 CONNECTOR X5,X6 - modbus RS485 Figure 8 X4, X5 connector Nr. Pin Name Descrption Note D-SUB 9 pin male For last module connected to serial n.c. Not used line. + Tx/Rx RS485 serial (A+) Connect the termination resistor Terra Ground (cable shield) as shown in the figure (inside the connector).
- Page 16 onnection examPle ower section Connection example: IR-24 connected to 24 loads Figure 10a 80380A_MHW_IR-12/IR-24_11-2015_ENG...
- Page 17 Connection example: IR-12 connected to 12 loads Figure 10b 80380A_MHW_IR-12/IR-24_11-2015_ENG...
-
Page 18: Burst Firing Mode
Firing modes The IR24- IR12 power controllers have the following control modes: - modulation by variation of phase angle - modulation by variation of number of conduction cycles with “zero crossing”, Burst Firing or Half Single Cycle firing Burst Firing mode BF -with variable cycle time This mode manages power on the load by means of a series of conduction (ON) and non-conduction (OFF) cycles. -
Page 19: Additional Functions
4 Phase angle (PA) This mode controls power on the load via modulation of trigger angle q Example: if power to be transferred to the load is 100%, q = 180° if power to be transferred to the load is 50%, q = 90° Figure 13 Inductive load Resistive load... - Page 20 It is positively identified by means of a node address (ID) set on rotary switches (tens + units). A maximum of 99 IR-12/IR-24 controller, modules can be installed in a serial network, with node address selectable from “01” to “99” IR-12/IR-24 controller modules have a ModBus serial...
-
Page 21: Installation Of Serial Network
1) Connect the serial cables for all modules on the network t and to the supervision terminal. 2) Set the rotary switch on the IR-12/IR-24 modules to INSTALLATION OF be installed, or on all modules present in case of first SERIAL NETWORK 1 installation, to position “0+0”. -
Page 22: Technical Characteristics
5 • TECHNICAL CHARACTERISTICS INPUTS INDIG Digital Inputs Function N. 4 configurable digital inputs Voltage range 18-30V (max 15 mA) Safe voltage read status “0” < 15 V Safe voltage read status “1” > 18 V Line voltage measurement Line voltage measurement function (F - N) Measure RMS voltage for each phase, phase/neutral Working voltage range: 90...300VAC) Accuracy of RMS voltage measurement... -
Page 23: General Information
Single-phase load (Phase/Neutral) 8 loads for each phase maximum Protection level IP20 Working / Storage temperature 0…40°C Cooling N.2 fans 24Vdc - 3,6W (only one fan for IR-12 models) Relative humidity 10…95% Ur non-condensing Ambient operating conditions internal use, max. altitude 2000 meters Installation... -
Page 24: Technical / Commercial Information
It is available the SW Configuration tool “GF-eXpress” cod. F043958, useful for quick IR-24 / IR-12 configuration using a PC with a USB / RS485 serial port. It is also available the accessory cable USB/RS485 cod. F062615 useful for models with Modbus communication, to be connected to PC computer with USB port.
