RLX CONTROL HANDLE
O. M. 10574
MC FILE NUMBER: 733-0186
DATE OF ISSUE:
REVISION:
WARNING
Do not proceed with
these instructions until
you have READ the
orange cover of this
MANUAL and YOU
UNDERSTAND its
contents. *
These WARNINGS are
included for the health
and safety of the
operator and those in
the immediate vicinity.
*If you are using a Clemco Distributor
Maintenance and Part Guide, refer to
the orange warnings insert preceding
the Index before continuing with the
enclosed instructions.
Electronic files include a Preface
containing the same important
information as the orange cover.
01/86
I, 11-09
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clemco RLX
Summary of Contents for Clemco RLX
- Page 1 © 2009 CLEMCO INDUSTRIES CORP. One Cable Car Dr. *If you are using a Clemco Distributor Washington, MO 63090 Maintenance and Part Guide, refer to Phone (636) 239-4300 Fax (800) 726-7559 the orange warnings insert preceding Email: info@clemcoindustries.com...
-
Page 2: General Instructions
DO NOT modify or substitute any Clemco parts with other The products described in this material may be combined by types or brands of equipment. Unauthorized modification... - Page 3 ALWAYS attach safety cables at ALL air hose AND blast 1910.244). hose coupling connections. Cables relieve tension on hose and control whipping action in the event of a coupling blow-out. • NEVER modify OR substitute remote control parts. Parts from different manufacturers are NOT compatible with Clemco...
-
Page 4: Maintenance
• Training and Educational Programs. free of the rightful claim of any third party by way of patent Clemco Industries Corp. offers a booklet, Blast-Off 2, infringement or the like. developed to educate personnel on abrasive blast equipment 6. This warranty is conditioned upon seller’s receipt within ten function and surface preparation techniques. - Page 5 PREFACE □ □ 3. Clean, properly maintained NIOSH-APPROVED 8. BLAST HOSE with ID 3 to 4 times the nozzle orifice. SUPPLIED-AIR RESPIRATOR. ALL components should Lines MUST be run AS STRAIGHT AS POSSIBLE from ALWAYS be present. NEVER operate without inner lens in machine to work area with NO sharp bends.
- Page 6 Caution used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property Twist-Lock Connector For use with 05801 damage. only Figure 1 © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574...
-
Page 7: Installation
Electric Remote Controls have anti-freeze off incoming control air, and simultaneously opens the injectors mounted on the control box. control box exhaust port so blasting stops. © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574... -
Page 8: Operation
Band the cord to the blast hose on both 3.2.1.3 Both the handle lever and safety lever lock must sides of all connections. move freely with no drag or binding. © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574... - Page 9 WARNING Be prepared for the recoil from the blast hose. Blasting will begin within a few seconds after pressing the control handle lever. © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574...
- Page 10 Pull the stem to seat the button. Shoulder Screw 4.6.1.3 Trim the button stem flush with the top of the handle lever. Figure 3 © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574...
-
Page 11: Troubleshooting
5.1.2.2 Inspect the spring for damage or fatigue. 4.7.2.3 Loosen the cable clamp and set screws holding 5.1.2.3 Replace lever lock or spring as necessary. the cord, and remove the cord from the assembly. © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574... - Page 12 Faulty solenoid. • Metering valve requires service. Refer to the metering 5.3.2.2 Make sure the return spring raises the handle valve manual for operation of the valve. lever fully up. © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574...
-
Page 13: Replacement Parts
Adaptor, 1/8" NPT (2 required) ...... 01940 Screw, 8-32 x 1" Tie, nylon wire ..........02195 Screw, 4-40 x 3/8" Rubber button Gasket, pneumatic adaptor Screw, 8-32 x 3/8" Figure 6 Figure 6a © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574... - Page 14 " shoulder (2 required) ..05817 Ties, nylon wire ..........02195 Connector, Lo-Profile male (for 10840 only) ........... 10828 Connector, Twist-Lock male (for 05801 only) ........... 02899 Figure 7 Figure 8 © 2009 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No. 10574...
