INEX SUCTION BLAST CABINET
With VACUUM COLLECTOR
Clemco Industries Corp. • One Cable Car Drive • Washington, MO 63090
Phone: (636) 239-4300 • Fax: (800) 726-7559
Email: info@clemcoindustries.com
www.clemcoindustries.com
NOTICE TO PURCHASERS AND USERS OF OUR PRODUCTS
AND THIS INFORMATIONAL MATERIAL
The products described in this material, and the information relating to
those products, is intended for knowledgeable, experienced users of
abrasive blasting equipment.
No representation is intended or made as to the suitability of the products
described herein for any particular purpose of application. No representations
are intended or made as to the efficiency, production rate, or the useful life of
the products described herein. Any estimate regarding production rates or
production finishes are the responsibility of the user and must be derived solely
from the user's experience and expertise, and must not be based on
information in this material.
The products described in this material may be combined by the user in a
variety of ways for purposes determined solely by the user. No
representations are intended or made as to the suitability or engineering
balance of the combination of products determined by the user in his
selection, nor as to the compliance with regulations or standard practice of
such combinations of components or products.
It is the responsibility of the knowledgeable, experienced users of the products
mentioned in this material to familiarize themselves with the appropriate laws,
regulations and safe practices that apply to these products, equipment that is
connected to these products, and materials that may be used with these
products.
It is the responsibility of the user to insure that proper training of operators has
been performed and a safe work environment is provided.
Our company is proud to provide a variety of products to the abrasive blasting
industry, and we have confidence that the professionals in our industry will
utilize their knowledge and expertise in the safe efficient use of these products.
OWNER'S MANUAL
© 2005 CLEMCO INDUSTRIES CORP. • Stock No.: 11217 • Manual No.: 833-0288 • Date of Issue: 02/88, Rev. E, 03/05
Advertisement
Table of Contents
Related Manuals for Clemco Zero
Summary of Contents for Clemco Zero
- Page 1 OWNER’S MANUAL © 2005 CLEMCO INDUSTRIES CORP. • Stock No.: 11217 • Manual No.: 833-0288 • Date of Issue: 02/88, Rev. E, 03/05...
- Page 2 Media sizes noted are intended as guidelines only, and © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
- Page 3 Compressed Air Requirements cause electric shock and equipment damage. 1.7.1 The size of the compressor required to operate the cabinet depends on the size of the air jet and © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
-
Page 4: Installation
Parts must be free of oil, water, grease, or other grounding lug on the left rear of the cabinet. contaminants that will cause media to clump, or clog the filter. © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05... - Page 5 If pulsation occurs in the media hose, either media pedal. is damp and caked, or not enough air is entering the media stream. While blasting, loosen the locking nut and slowly © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
-
Page 6: Preventive Maintenance
To avoid unscheduled down-time, periodically inspect the media hose for thin spots, by pinching it every 6 to 12 inches. Replace the hose when in becomes soft.. © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05... -
Page 7: Service & Maintenance
Swing the light-shield up and tie it in place, as shown in Figure 5. 6.3.2. Remove the filler strip by pulling it out of the window molding, as shown if Figure 5. Figure 7 © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05... - Page 8 Figure 10, and work the window channel lip over the glass. When this is done, the window should be entirely within the molding’s window channel. © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
-
Page 9: Troubleshooting
Blocked air inlet duct. Blockage in the air intake 7.4.2 Media mixture too rich. Adjust media/air mixture ducts restricts incoming air and reduces air movement in per Section 4.3. the cabinet. © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05... - Page 10 Make sure that the 3-way valve in the foot pedal cabinet. exhausts air when the pedal is released. If it does not, check the line for blockage, and check the switch for defect. © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
- Page 11 Wide spray nozzle nut Knurled brass ..........11916 Urethane covered ........12906 Wide spray retaining ring ......12038 Wide spray nozzle guard ......12295 Orifice adjusting tool ........19041 Figure 13 Figure 14 © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
- Page 12 Adaptor, 10-32 thrd. x 1/8 barb ....11731 Spring, 1-1/4" x 3-1/2" ........20121 Screw, 8-32 x 3/8″ thread cutting ....11389 Figure 16 Bumper, rubber (feet) ........21522 © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
- Page 13 Filter, 1/2" manual drain .......01308 Metering valve assembly ......12417 Adaptor, 1/2" NPT x 1/2" flare ......11351 To ″IN″ on valve To ″OUT″ on valve Compressed Air Inlet Figure 18 © 2005 CLEMCO INDUSTRIES CORP. • www.clemcoindustries.com • Manual No11217 Rev. E 03/05...
