MEDIA RECLAIMER/SEPARATOR
Clemco Industries Corp. • One Cable Car Drive • Washington, MO 63090
Phone: (636) 239-4300 • Fax: (800) 726-7559
Email: info@clemcoindustries.com
www.clemcoindustries.com
NOTICE TO PURCHASERS AND USERS OF OUR PRODUCTS
AND THIS INFORMATIONAL MATERIAL
The products described in this material, and the information relating to those
products, is intended for knowledgeable, experienced users of abrasive blasting
equipment.
No representation is intended or made as to the suitability of the products
described herein for any particular purpose of application. No representations
are intended or made as to the efficiency, production rate, or the useful life of
the products described herein. Any estimate regarding production rates or
production finishes are the responsibility of the user and must be derived solely
from the user's experience and expertise, and must not be based on
information in this material.
The products described in this material may be combined by the user in a
variety of ways for purposes determined solely by the user. No representations
are intended or made as to the suitability or engineering balance of the
combination of products determined by the user in his selection, nor as to the
compliance with regulations or standard practice of such combinations of
components or products.
It is the responsibility of the knowledgeable, experienced users of the products
mentioned in this material to familiarize themselves with the appropriate laws,
regulations and safe practices that apply to these products, equipment that is
connected to these products, and materials that may be used with these
products.
It is the responsibility of the user to insure that proper training of operators has
been performed and a safe work environment is provided.
Our company is proud to provide a variety of products to the abrasive blasting
industry, and we have confidence that the professionals in our industry will
utilize their knowledge and expertise in the safe efficient use of these products.
OWNER'S MANUAL
© 2005 CLEMCO INDUSTRIES CORP. • Stock No.: 23438 • Manual No.: 2161-0202 • Date of Issue: 02/27/02, Rev. E, 04/05
Advertisement
Table of Contents
Related Manuals for Clemco ZERO Blast Cabinets
Summary of Contents for Clemco ZERO Blast Cabinets
- Page 1 OWNER’S MANUAL © 2005 CLEMCO INDUSTRIES CORP. • Stock No.: 23438 • Manual No.: 2161-0202 • Date of Issue: 02/27/02, Rev. E, 04/05...
- Page 2 Safety Alerts Suction type reclaimers are identified by the conical 1.2.1 Clemco uses safety alert signal words, bottom, adapted for the attachment of BNP style media based on ANSI Z535.4-1998, to alert the user of a metering valve(s), or media valve manifold.
- Page 3 900 cfm. 1200 cfm and Larger Pull-Through Suction Style with Rubber Liners 1200 cfm and Larger Exhauster-Mount Pressure Style Some Item Are Rotated For Clarity Figure 1 © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
- Page 4 The reclaimer utilizes most common reusable removed. Consult the factory before proceeding with this media specifically manufactured for dry blasting or option. Reclaimers can be ordered from the factory © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
-
Page 5: Installation
(equipment built around user specifications). Place the reclaimer as close as possible to the orientation or as shown on the floor plan of those drawings. © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com... - Page 6 Make sure each end exhauster outlet of reverse-pulse collectors. is securely fastened with clamps to prevent media and dust from escaping. © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
-
Page 7: Operation
If media doesn't flow, it has © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com... - Page 8 Note: If the manometer installation is permanent, the manometer may remain on the reclaimer body after the Figure 4 valves are closed. © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
- Page 9 Section 5.1. After the size, weight and type of media. Use the table in Figure 6 © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
- Page 10 When the correct setting is established, Tighten the locking nut finger-tight to maintain the setting. tighten the bolts to prevent movement. © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
-
Page 11: Service & Maintenance
NOTE: Inlet baffles are tack-welded to the inner tube. Before removing the baffle, make an alignment © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com... -
Page 12: Troubleshooting
Secure switch the motor leads as shown on the motor plate. the top bolts and inlet baffle bolts. Refer to the system’s wiring schematic. © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com... - Page 13 Blockage in media hose or blast gun. Blockage airtight container when cabinet is not in use. may occur as a result of a missing debris screen or © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
-
Page 14: Replacement Parts
Reclaimer assembly, pull-through Suction type 900 cfm ..........21305 1200 cfm ..........21306 1800 cfm ..........21307 Pressure type 900 cfm, for 16" blast machine ..21293 © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com... - Page 15 2500 cfm ..........22704 Inlet top 900 cfm ..........22827 1200 cfm ..........24031 1800 cfm ..........24032 2500 cfm ..........24033 Screw, self drilling, 10-16 x 3/4″ ....12722 Figure 10 Figure 11 © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
- Page 16 Gasket, 1/8" x 2" adhesive backed, 900 cfm ..........11745 specify ft. required ......... 13089 1200, 1800 and 2500 cfm ..... 11766 1200 cfm and Larger 900 cfm Figure 12 © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
- Page 17 Manifold, multiple metering valve, 3" inlet for use with up to 12 blast guns ....16202 Metering stem assembly (items 2, 3, & 4) .23889 Figure 13 © 2005 CLEMCO INDUSTRIES CORP. • • Manual No. 23438 • Rev. E www.clemcoindustries.com...
