DATABOOK / SERVICE MANUAL
X-POWER Full DC Inverter Outdoor Unit
208~230V
Thank you very much for purchasing our air conditioner, Before using your air conditioner, please read
this manual carefully and keep it for future reference.
Caution: The manual is applicable for the cooling&heating and cooling only outdoor unit. The
cooling&heating indoor unit is applicable for the cooling&heating and cooling only outdoor unit; the
heating capacity of the indoor unit will be effective only when the indoor unit connect to the
cooling&heating outdoor unit.
