Install The Four-Post Mounting Shelf And Rear Support Bracket - Juniper TX Matrix Plus Quick Start Manual

TX Matrix Plus Router Quick Start
6
Table 2: Mounting Hole Locations for Installing a TX Matrix Plus Chassis
in a Four-Post Rack (continued)
Hole Distance Above U Division
75 43.50 in. (110.5 cm)
69 40.00 in. (101.6 cm)
63 36.5 in. (92.7 cm)
57 33.00 in. (88.8 cm)
51 29.50 in. (74.9 cm)
45 24.26 in. (61.6 cm)
39 22.51 in. (57.2 cm)
33 19.01 in. (48.3 cm)
27 15.51 in. (39.4 cm)
21 12.00 in. (30.5 cm)
15 8.50 in. (21.6 cm)
9 5.00 in. (12.7 cm)

Install the Four-Post Mounting Shelf and Rear Support Bracket

To install the four-post mounting shelf and rear support bracket (see
On the rear of each rear rack rail, partially insert a mounting screw into the lowest hole
1.
specified in Table 1 on page
Install the rear support bracket on the rear of the rear rack rails. Rest the bottom slot
2.
of the rear support bracket on a mounting screw. The rear support bracket extends
toward the center of the rack.
Partially insert screws into the open holes in the rear support bracket.
3.
Tighten all the screws completely.
4.
On the front of each front rack rail, partially insert a mounting screw into the lowest
5.
hole specified in Table 1 on page
Install the four-post rack mounting shelf on the front rack rails. Rest the bottom slot
6.
of the front flange on a mounting screw. Rest the back of the four-post rack mounting
shelf on top of the rear support bracket.
Tighten all the screws completely.
7.
24.86 U
22.86 U
20.86 U
18.86 U
16.86 U
14.86 U
12.86 U
10.86 U
8.86 U
6.86 U
4.86 U
2.86 U
5.
5.
Copyright © 2015, Juniper Networks, Inc.
Figure 2 on page 7):
