TX Matrix Plus Router Quick Start

Step 9: Power On the TX Matrix Plus Router

28
Figure 16: Installing an Input Power Tray
Verify that the power cables are not touching or blocking access to TX Matrix Plus
21.
components, and that they do not drape where people could trip on them.
To power on the router:
Verify that the power supplies are fully inserted in the chassis and that the captive
1.
screws and ejector handles on the faceplates are tightened.
Verify that the source power cables are connected to the appropriate terminal: the
2.
positive (+) source cable to the return terminal (labeled
source cable to the input terminal (labeled
Verify that an external management device is connected to one of the Routing Engine
3.
ports on the TXP-CB (
AUX
NOTE: The management Ethernet port labeled
is not available until after the initial TX Matrix Plus router software
configuration. You can monitor the startup process during the initial
installation using devices connected to the
Verify that the
4. SFC CHASSIS NUMBER
See Verifying the Configuration Size and Switch-Fabric Chassis Number Settings.
Turn on the power to the external management device.
5.
Switch on the customer site circuit breakers to provide voltage to the DC power source
6.
cables.
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
7.
the strap to one of the ESD points on the chassis.
Tighten captive screws.
Input power tray
).
–48V
or ).
CONSOLE
and
CONFIG SIZE
Copyright © 2015, Juniper Networks, Inc.
) and the negative (–)
RTN
ETHERNET on the TX-CB
or ports.
AUX CONSOLE
switches are set correctly.
