Johnson Controls VSD II Series Installation Manual Addendum page 14

LIT-12012316
Effective May 2017
Series II Technical Data, continued
Attribute Description
EMC (at default
Immunity
settings)
Emissions
Noise level Average noise level
(cooling fan) sound pow-
er level in dB (A)
Safety
-
Protections Overvoltage trip limit
Undervoltage trip limit
Eart fault protection
Mains supervision
Motor phase supervision
Overcurrent protection
Unit overtemperature
protection
Motor overload protection
Motor stall protection
Motor underload protec-
tion
Shart-circuit protection of
24V and 10V reference
voltage
14
Specification
Fulfils EN61800-3 (2004), first and second environment
EN61800-3 (2004), Category C3
The drive can be modified for IT-networks
FS5: 65
FS6: 72
FS7: 73
EN61800-5-1 (2007), CE, cUL (see nameplate for more
detailed approvals)
600V drives: 1094Vdc
Depends on supply voltage (0,8775*supply voltage):
Supply voltage 600V: Trip limit 527V
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
www.johnsoncontrols.com
Series II Installation Manual Addendum
FS8: 73
FS9: 75
